Mara 1998

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
PF21 Manaure PF22 Mara PF23 Guaicaipuro PF24 Tamanaco	Venezuela: PF21-24	1973: PF21-24	none	none	in service (2019): PF21-24

Technical data

Displacement standard, t	14
Displacement full, t	18
Length, m	16.5
Breadth, m	4.30
Draught, m	1.30
No of shafts	2
Machinery	2 diesels
Power, h. p.
Max speed, kts	10
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	PF21, 22: 1 x 1 - 20/70 Mk 10, 1 x 1 - 12.7/90 PF23, 24: 1 x 1 - 12.7/90
Electronic equipment	Raytheon 6410 radar
Complement	8

Graphics

Project history

Assigned to River Command. Resembled USN Swiftboat.

Modernizations

None.

Naval service

No significant events.
