 Henrique Dias 1946

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Pampano			Henrique Lage, Ilha do Viana, Brazil		10.10.1942	11.1943 // ---	purchased by Brazilian navy 8.1942 (Mathias de Albuqerque)
Papaterra			Henrique Lage, Ilha do Viana, Brazil		2.1942	6/1943 // ---	purchased by Brazilian navy 8.1942 (Felipe Camarao)
Parati			Henrique Lage, Ilha do Viana, Brazil		10.10.1942	11.1943 // ---	purchased by Brazilian navy 8.1942 (Fernandes Vieira)
Pargo			Henrique Lage, Ilha do Viana, Brazil		28.8.1942	9.1943 // ---	purchased by Brazilian navy 8.1942 (Henrique Dias)
Paru			Henrique Lage, Ilha do Viana, Brazil		2.1944	10/1944 // ---	purchased by Brazilian navy 8.1942 (Barreto de Menezes)
Pelegrime			Henrique Lage, Ilha do Viana, Brazil		12.1942	1.1944 // ---	purchased by Brazilian navy 8.1942 (Vidal de Negreiros)

Technical data

Displacement standard, t	813
Displacement full, t	920
Length, m	48.8 pp 53.8 oa
Breadth, m	8.53
Draught, m	4.88
No of shafts	1
Machinery	1 VTE, 1 boiler
Power, h. p.	1000
Max speed, kts	12.5
Fuel, t	coal
Endurance, nm(kts)
Armament	2 x 1 - 76/40 12pdr 12cwt QF Mk I/II/V, 4 DCT, mechanical minesweeping gear
Electronic equipment	type 122 sonar
Complement	70

Standard scale images

Graphics

Project history

Dual-purpose, minesweeping and  ASW trawlers. All units of this class were purchased by Brazilian navy when built.

Modernizations

None.

Naval service

No significant events.
