MGB86

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
MGB82 - 93 (ex-PTC1 - 12)	Elco, Bayonne, USA: MGB82-93	2 - 3.1941 // 4 - 7.1941: MGB82-93	MGB90 (16.7.1941), MGB92 (16.7.1941)	none	to USA 4-9/1945: MGB82-89, 91, 93

Technical data

Displacement standard, t	32 as designed
Displacement full, t	45
Length, m	21.3
Breadth, m	6.30
Draught, m	1.60
No of shafts	3
Machinery	3 Packard petrol engines
Power, h. p.	4050
Max speed, kts	39
Fuel, t	petrol 13600 l
Endurance, nm(kts)
Armament	1 x 1 - 20/70 Oerlikon Mk 2.4, 2 x 2 - 12.7/90, 2 DC
Complement	17

Standard scale images

Graphics

Project history

Transferred to RN by lend-lease.

Modernizations

1941, all survived: - 2 x 2 - 12.7/90; + 2 x 2 - 12.7/62

1942-1943, most survived: + type 286PU or type 291U radar

Naval service

No significant events.
