Wrangel 1918 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Wrangel	9 - 25	429	Lindholmen, Göteborg	1916	24.9.1917	5.1918	stricken 6.1947
Wachtmeister	10 - 26	430	Lindholmen, Göteborg	1916	19.12.1917	10.1918	stricken 6.1947

Technical data

Displacement standard, t	415
Displacement full, t	498
Length, m	69.6 wl 72.0 oa
Breadth, m	6.90
Draught, m	2.40 mean 2.80 max
No of shafts	2
Machinery	2 sets de Laval geared steam turbines, 4 Yarrow boilers
Power, h. p.	13000
Max speed, kts	34
Fuel, t	coal 105
Endurance, nm(kts)	1300(18)
Armament	4 x 1 - 75/49 K/50 M12, 2 x 1 - 6.5/106, 2 x 2 - 450 TT, 2 x 1 - 450 TT
Complement	81

Standard scale images

Graphics

Project history

Destroyers of Wrangel class have finished a line of development of Swedish 30kts destroyers, originating from Wale. Unlike the ships of the previous series, they have received the forecastle which notably has raised seaworthiness, and their steam turbines were geared for the first time in the Swedish navy. Armament repeated predecessors, only two additional single torpedo tubes were installed under a forecastle, shooting through ports in side plating, covered by folding boards.

It was planed to built a series of four ships, but the order of the second pair of obsolete destroyers have refused.

Modernizations

1927, both: boilers were converted to oil-firing (105t of oil)

1940, both: - 2 x 1 - 450 TT; + 1 x 1 - 25/55 K/58 M32, 1 x 2 - 8.76, 2 DCR, displacement was 498/570t.

Naval service

No significant events.
