NAVYPEDIA


Jayesagara 2004

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
ජයෙසගර [Jayesagara]	P601		Colombo DYd	5/1982	26.5.1983	9.12.1983	in service (2019)
සගරවර්දේනේ [Sagarawardene]	P602		Colombo DYd	7/1982	20.11.1983	4.6.1984	sunk 19.9.1994

Technical data

Displacement standard, t	315
Displacement full, t	330
Length, m	39.8
Breadth, m	7.00
Draught, m	2.10
No of shafts	2
Machinery	2 MAN 8L20/27 diesels
Power, h. p.	2180
Max speed, kts	15
Fuel, t	diesel oil
Endurance, nm(kts)	3000(11)
Armament	1 x 2 - 25/82 type 61, 1 x 2 - 14.5/93, 2 x 1 - 12.7/79, 2 x 1 - 7.6/90
Electronic equipment	Anritsu RA723UA radar
Complement	52

Graphics

Project history

Two offshore patrol vessels of domestic design ordered in 1981.

Modernizations

None.

Naval service

Sagarawardene was sunk 19.9.1994 by Tamil Tiger insurgent explosive suicide boats.
