Ankaran 2010

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P112 Ankaran, later- 21 Ankaran	Israeli Aircraft Industries, Ramta, Israel: P112	1996: P112	none	none	in service (2020): 21

Technical data

Displacement standard, t	50
Displacement full, t	58
Length, m	24.0
Breadth, m	5.60
Draught, m	1.50
No of shafts	2
Machinery	2 General Motors Detroit Diesel 16V92TA diesels
Power, h. p.	4200
Max speed, kts	42
Fuel, t	diesel oil
Endurance, nm(kts)	700(30)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 7.6/90
Electronic equipment	Raytheon radar, MSIS e/o system
Complement	15

Graphics

Project history

Israeli Super Dvora Mk 2 design.

Modernizations

None.

Naval service

Ankaran was at first commissioned by Police and transferred to Navy later.
