Spidola

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Ронис [Ronis] (ex-Ronis)			A C de la Loire, Nantes, France	1925	1.7.1926	1927 // 8.1940	scuttled 24.6.1941
Спидола [Spidola[ (ex-Spidola)			A C de la Loire, Nantes, France	1925	6.10.1926	1927 // 8.1940	scuttled 24.6.1941

Technical data

Displacement standard, t
Displacement normal, t	390 / 514
Length, m	55.0
Breadth, m	4.80
Draught, m	3.60
No of shafts	2
Machinery	2 Sulzer diesels / 2 electric motors
Power, h. p.	1300 / 700
Max speed, kts	14 / 9
Fuel, t	diesel oil 19
Endurance, nm(kts)	1600(14) /
Armament	1 x 1 - 75/34 M1925, 6 - 450 TT (2 bow, 2 x 2 turnable, 8)
Complement	27
Diving depth operational, m	50

Standard scale images

Graphics

Project history

Former Latvian Ronis and Spidola. Ordered in France under design of Simoneaut. Single-hulled submarines with traditional for French submarines arrangement of TTs: 2 fixed in a bow of a pressure hull and 2 twin trained on deck, out of a pressure hull (thanks to protective boards they entered into light hull lines). Trained deck TTs can be reloaded only in base.     With occurrence of Latvia into the USSR 19.8.1940 both entered Red Navy, but at once have been put into repair and never been maintained by Soviet crews.

Modernizations

None.

Naval service

Ronis and Spidola 23.6.1941 were blown up at Libava. They were salvaged by Germans and scrapped in 1943.
