Paltus 1907 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Осётр [Osyotr] (ex-Protector)			Lake, Bridgeport, USA	1901	1.11.1902	8/1905	stricken 8.1913
Бычок [Bychok]		51	Newport News SB, USA // Libava N Yd	1904	22.11.1905	1906	stricken 11.1913
Палтус [Paltus]		52	Newport News SB, USA // Libava N Yd	1904	12.12.1905	1906	stricken 11.1913
Плотва [Plotva]		53	Newport News SB, USA // Libava N Yd	1904	22.11.1905	1906	stricken 11.1913
Кефаль [Kefal']		54	Newport News SB, USA // Libava N Yd	1904	18.5.1905	10/1905	deleted 4.1916
Сиг [Sig]		55	Newport News SB, USA // Libava N Yd	1904	7/1905	8/1905	stricken 7.1914

Technical data

Displacement standard, t
Displacement normal, t	Osyotr: 136 / 174 others: 153 / 187 - 189
Length, m	Osyotr: 19.8 others: 22.0
Breadth, m	Osyotr: 3.40 others: 3.50 - 3.60
Draught, m	3.70
No of shafts	2
Machinery	2 gasoline engines / 2 electric motors
Power, h. p.	Osyotr: 240 / 120 others: 240 / 130
Max speed, kts	Osyotr: 8.5 / 5.6 others: 7.4 - 8.3 / 4.6 - 5
Fuel, t	gasoline
Endurance, nm(kts)	250 - 350 (5) / 17 - 30(3)
Armament	3 - 450 TT (2 bow, 1 stern, 5)
Complement	12
Diving depth operational, m	30 max

Standard scale images

Graphics

Project history

Five ordered on 10 May 1904 from the Simon Lake Wks under the 1904 Emergency Programme, while Protector was bought to lead assembly of the whole series and arrived at Kronstadt on 15 June. Renamed Osyotr ('Sturgeon'), she had hydraulically operated wheels (stowed within the keel) to allow the submarine to move on the sea bed and was fitted with a chamber to embark divers when submerged.

Modernizations

None.

Naval service

No significant events.
