NAVYPEDIA


Vladimir Gumanenko 2002

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Железняков [Zheleznyakov]	901	561	Sredne-Nevskiy SYd, Pontonnyy	28.2.1985	17.7.1986	30.12.1988	in service (2019)
Владимир Гуманенко [Vladimir Gumanenko]	811	562	Sredne-Nevskiy SYd, Pontonnyy	15.9.1985	4.3.1991	2000	in service (2019)
---		563	Sredne-Nevskiy SYd, Pontonnyy	1986	---	---	suspended 1991

Technical data

Displacement standard, t	1070
Displacement full, t	1150
Length, m	67.8
Breadth, m	11.0
Draught, m	3.12
No of shafts	2
Machinery	2 M-503B-37 diesels
Power, h. p.	5000
Max speed, kts	15.7
Fuel, t	diesel oil
Endurance, nm(kts)	1500(12)
Armament	2 x 4 Strela-3 SAM (16 9M36), 1 x 1 - 76/59 AK-176M, 1 x 6 - 30/54 AK-630M, 16 mines, 2 x 4 - 400 Giurza mine countermeasures system launchers, Ketmen', Paltus USVs, KTK-1 mechanical, TEM-3M magnetic, AT-3 acoustic minesweeping gear, ShZ-3 mine clearance line charges
Electronic equipment	MR-123-01 Vympel-A, 2x MR-212/201 Vaygach-U radars, MG-99 Kabarga-A3, MG-7 Braslet sonars, 2x PK-16 decoy RL
Complement	68

Standard scale images

Graphics

Project history

Oceangoing minesweeper intended to use new mine countermeasures systems as Giurza anti-mine expendable drones, Ketmen' and Paltus USVs.

Modernizations

2016, Vladimir Gumanenko: - MG-7 Braslet sonar; + MG-757.1 Anapa sonar

Naval service

No significant events.
