VLADIMIR POLUKHIN minesweepers (projects 59, 73K) (1942 - 1950)





T-250 Vladimir Polukhin

Ships


Name No Yard No Builder Laid down Launched Comp Fate Modification
Т-250 Владимир Полухин [T-250 Vladimir Polukhin]   108 370 Yd, Leningrad 5.1939 30.3.1940 11.1942 test ship Форель [Forel] 12.1954 project 59
Т-254 Василий Громов [T-254 Vasiliy Gromov]   23 363 Yd, Leningrad 5.1939 8.10.1940 12.1943 repair ship ПМ-69 [PM-69] 1.1956 project 59
Т-251 Павел Хохряков [T-251 Pavel Khokhryakov]   109 370 Yd, Leningrad 1939 31.3.1940 --- BU incomplete 1945 project 73K and incomplete ships
Т-252 Александр Петров [T-252 Aleksandr Petrov]   110 370 Yd, Leningrad 1940 11.1940 --- BU incomplete 1945 project 73K and incomplete ships
Т-253 Карл Зедин [T-253 Karl Zedin]   111 370 Yd, Leningrad 1940 11.1940 9.1948 receiving vessel БРН-23 [BRN-23] 5.1956 project 73K and incomplete ships
Т-255 Андриан Засимов [T-255 Andrian Zasimov]   25 363 Yd, Leningrad // 370 Yd, Leningrad 1940 15.9.1940 2.1950 rescue vessel Агатан [Agatan] 1956 project 73K and incomplete ships
Т-256 Владимир Трефолев [T-256 Vladimir Trefolev]   26 363 Yd, Leningrad 1940 3.12.1940 12.1947 training hulk УТС-2 [UTS-2] 1956 project 73K and incomplete ships
Т-257 Тимофей Ульянцев [T-257 Timofey Ulyantsev]   124 370 Yd, Leningrad 1940 29.5.1940 1.1949 test ship Лосось [Losos] 1956 project 73K and incomplete ships
Т-258 Михаил Мартынов [T-258 Mikhail Martynov]   125 370 Yd, Leningrad 1940 30.5.1941 8.1948 receiving ship БРН-22 [BRN-22] 1956 project 73K and incomplete ships
Т-259 Фёдор Митрофанов [T-259 Fiodor Mitrofanov]   29 363 Yd, Leningrad // 370 Yd, Leningrad 8.1940 30.5.1941 11.1947 test ship ОС-12 [OS-12] 1954 project 73K and incomplete ships
Т-260 Лука Паньков [T-260 Luka Pankov]   30 363 Yd, Leningrad // 370 Yd, Leningrad 1940 30.5.1941 2.1948 test ship Палтус [Paltus] 1956 project 73K and incomplete ships
Т-261 Павлин Виноградов [T-261 Pavlin Vinogradov]   31 363 Yd, Leningrad // 370 Yd, Leningrad 1940 7.1941 9.1949 test ship ОС-11 [OS-11] 1954 project 73K and incomplete ships
Т-262 Степан Грядушко [T-262 Stepan Griadushko]   32 363 Yd, Leningrad // 370 Yd, Leningrad 1940 8.1941 9.1949 receiving ship БРН-24 [BRN-24] 1956 project 73K and incomplete ships
Т-263 Семён Пелихов [T-263 Semion Pelikhov]   33 363 Yd, Leningrad // 370 Yd, Leningrad 1940 8.1941 9.1949 test ship ОС-2 [OS-2] 1956 project 73K and incomplete ships
Т-450 Павел Головин [T-450 Pavel Golovin]   250 201 Yd, Sevastopol 8.1939 8.2.1940 --- wrecked incomplete 1942 project 73K and incomplete ships
Т-451 Иван Борисов [T-451 Ivan Borisov], 9.1948- ЭМТЩ-15 [EMTShch-15]   249 201 Yd, Sevastopol 8.1939 31.12.1939 9.1948 receiving ship БРН-17 [BRN-17] 5.1956 project 73K and incomplete ships
Т-452 Сергей Шувалов [T-452 Sergey Shuvalov], 9.1948- ЭМТЩ-11 [EMTShch-11]   251 201 Yd, Sevastopol 11.1939 1941 4.1948 receiving ship БРН-16 [BRN-16] 5.1956 project 73K and incomplete ships
Т-453 Семён Рошаль [T-453 Semion Roshal]   252 201 Yd, Sevastopol 1940 16.1.1941 --- wrecked incomplete 1944 project 73K and incomplete ships
Т-454 Иван Сладков [T-454 Ivan Sladkov], 1948- ЭМТЩ-13 [EMTShch-13]   253 201 Yd, Sevastopol 1940 20.3.1941 4.1948 receiving ship БРН-18 [BRN-18] 5.1956 project 73K and incomplete ships
Т-455 Николай Маркин [T-455 Nikolay Markin]   258 201 Yd, Sevastopol 1941 --- --- destroyed on the slip 9.1941 project 73K and incomplete ships


Technical data


Data variantpr. 59 pr. 73K
Displacement standard, t

690

703

Displacement full, t

879

863

Length, m

74.0 wl 79.2 oa

77.5 wl 78.6 oa

Breadth, m

8.10

8.10

Draught, m

2.50

2.48

No of shafts

2

2

Machinery

2 DK-1 geared steam turbines sets, 2 boilers

2 General Motors diesels

Power, h. p.

8000

3200

Max speed, kts

22.4

17.5

Fuel, t

oil 191

diesel oil

Endurance, nm(kts)2000(11) 3700(16)
Armament

2 x 1 - 100/54 B-24BM, 1 x 1 - 45/43 21K, 3 x 1 - 37/63 70K, 2 x 1 - 20/70 Oerlikon Mk IV, 4 x 1 - 12.7/79, 2 DCR (20), 20 mines, ShT-1, ZT-1 mechanical minesweeping gear

2 x 1 - 85/52 90K, 4 x 1 - 37/73 70K, 4 x 1 - 12.7/79, 2 DCT (20), 20 mines, PT, MT-2 mechanical, TEM-1 magnetic, 2x BAT-2 acoustic minesweeping gear

Electronic equipment --- Giuys-1M, Zarnitsa, Rym radars, Tamir-5 sonar
Complement

125

119



Standard scale images


<i>Vladimir Polukhin</i> 1942
Vladimir Polukhin 1942


Graphics


<i>T-451 Ivan Borisov</i>
T-451 Ivan Borisov
<i>T-250 Vladimir Polukhin</i>
T-250 Vladimir Polukhin


Project history

Fleet minesweepers intended for reconnaissance minesweeping in distant regions and anti-mine support of large surface ships squadrons. Owing to it the basic requirement to the project was 20kts speed, that has predetermined turbine machinery.     Designing works were begun in 1938. In 1939-1941 on No370 and No363 yards in Leningrad and No201 in Sevastopol 20 ships were laid down. Because of a delay of turbines and boilers availability to a beginning of war any of them have not been completed before war. In 1942-1943 it was possible to complete 2 ships. After war 15 ships were completed under project 73K with replacement of turbines by diesels, new sensors, strengthened AA armament and new anti-mine equipment.

Hulls of incomplete T-451 Ivan Borisov and T-452 Sergey Shuvalov were commissioned by Navy in December 1943 as non self-propelled landing barges and used in this role till 1944.

Modernizations

late 1940s, T-250 Vladimir Polukhin, T-251 Vasiliy Gromov: - mechanical minesweeping gear; + PT, MT-2 mechanical, TEM-1 magnetic, 2x BAT-2 acoustic minesweeping gear, Giuys-1M, Zarnitsa, Rym radars, Tamir-5 sonar

Naval service

No significant events.
