Project 35 1979

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
ПЛК-7 [PLK-7], 5.1966- СКР-7 [SKR-7]		164	820 Yd, Kaliningrad	1/1961	25.12.1961	29.12.1964	stricken 8.1987
ПЛК-20 [PLK-20], 5.1966- СКР-20 [SKR-20]		168	820 Yd, Kaliningrad	26.1.1961	23.3.1962	25.12.1964	stricken 5.1989
ПЛК-32 [PLK-32], 5.1966- СКР-32 [SKR-32]		169	820 Yd, Kaliningrad	21.3.1961	15.5.1962	29.12.1964	stricken 5.1989
ПЛК-39 [PLK-39], 5.1966- СКР-39 [SKR-39]		170	820 Yd, Kaliningrad	26.5.1961	23.6.1962	16.12.1964	stricken 4.1990
ПЛК-44 [PLK-44], 5.1944- СКР-86 [SKR-86]		171	820 Yd, Kaliningrad	10.8.1961	31.8.1962	31.12.1964	stricken 4.1990
ПЛК-49 [PLK-49], 5.1966- СКР-49 [SKR-49], 8.1968- Иван Сладков [Ivan Sladkov]		172	Yantar', Kaliningrad	17.10.1961	15.6.1962	25.6.1965	stricken 4.1990
ПЛК-53 [PLK-53], 5.1966- СКР-53 [SKR-53]		174	Yantar', Kaliningrad	30.11.1961	10.12.1962	31.8.1965	stricken 4.1990
ПЛК-8 [PLK-8], 5.1966- СКР-24 [SKR-24]		175	Yantar', Kaliningrad	14.3.1962	10.2.1963	30.9.1965	stricken 4.1990
ПЛК-51 [PLK-51], 5.1966- СКР-84 [SKR-84]		176	Yantar', Kaliningrad	17.5.1962	10.4.1963	29.12.1965	stricken 7.1992
ПЛК-48 [PLK-48], 5.1966- СКР-48 [SKR-48]		177	Yantar', Kaliningrad	28.6.1962	21.6.1963	31.12.1965	stricken 4.1990
СКР-12 [SKR-12] (ex-ПЛК-12 [PLK-12])		178	Yantar', Kaliningrad	12.9.1962	18.5.1963	30.5.1966	stricken 10.1992
СКР-19 [SKR-19] (ex-ПЛК-19 [PLK-19])		179	Yantar', Kaliningrad	25.2.1963	27.7.1964	30.6.1966	stricken 10.1992
СКР-35 [SKR-35] (ex-ПЛК-35 [PLK-35]), 7.1967- Гангутец [Gangutets]		180	Yantar', Kaliningrad	19.12.1962	27.9.1963	30.8.1966	stricken 4.1990
СКР-83 [SKR-83] (ex-ПЛК-55 [PLK-55]), 6.1980- 60 лет Комсомолу Белоруссии [60 Let Komsomolu Belorussii)		181	Yantar', Kaliningrad	20.7.1962	10.12.1963	3.9.1966	stricken 6.1991
СКР-6 [SKR-6] (ex-ПЛК-6 [PLK-6])		182	Yantar', Kaliningrad	10.4.1963	6.2.1964	30.11.1966	stricken 4.1990
СКР-13 [SKR-13] (ex-ПЛК-13 [PLK-13])		183	Yantar', Kaliningrad	31.5.1963	13.10.1964	28.12.1966	stricken 6.1991
СКР-90 [SKR-90]		184	Yantar', Kaliningrad	10.2.1964	30.11.1964	30.5.1967	stricken 4.1990
СКР-117 [SKR-117]		185	Yantar', Kaliningrad	15.10.1963	25.2.1965	29.6.1967	stricken 4.1990

Technical data

Displacement standard, t	940
Displacement normal, t	1136
Length, m	82.4
Breadth, m	9.10
Draught, m	3.00 mean 5.84 max
No of shafts	2 with hydroturbines
Machinery	164: CODAG: 2 D-2 gas turbines + 2 47B-16 diesels others: CODAG: 2 D-3 gas turbines + 2 61B diesels
Power, h. p.	164: 42000 (30000+12000) others: 48000 (36000+12000)
Max speed, kts	164: 30 others: 31
Fuel, t	oil
Endurance, nm(kts)	164: 2500(14) others: 2000(14)
Armament	164-176: 2 x 2 -76/59 AK-726, 1 x 5 - 400 TT, 4 x 12 RBU-6000 Smerch-2 ASWRL, 2 DCR 177-185: 2 x 2 - 76/59 AK-726, 2 x 5 - 400 TT, 2 x 12 RBU-6000 Smerch-2 ASWRL, 2 DCR
Electronic equipment	164-181: Fut-N, Fut-B, Don radars, MG-312I Titan, MG-311 Vychegda sonars, Bizan'-4B ECM suite 181-185: MR-302 Rubka, Fut-B, Don radars, MG-312I Titan, MG-311 Vychegda sonars, Bizan'-4B ECM suite
Complement	164: 102 others: 103

Standard scale images

Graphics

Project history

Designation changed from small ASW ship (PLK) to guard ship (SKR) 19.5.1966.

The Project 35 machinery arrangement recalls that of the earlier Project 204 corvettes. The gas turbine arrangement aft precludes installation of a towed (as opposed to a dipping) sonar aft.

Modernizations

1974, SKR-12; 1975, SKR-83; 1976, SKR-19; 1977, SKR-117; 1978, SKR-6, SKR-13, SKR-48; 1979, SKR-84, SKR-90; 1970s, Gangutets: - MG-312I Titan, MG-311 Vychegda sonars; + MGK-335MS Platina-MS, MG-349 Ros'-K sonars

1980s, SKR-12, SKR-84: - Ros'-K sonar; + Oka sonar

1980s, SKR-7: + Struya-M wake detector

1980s, some ships: + MG-329 Sheksna sonar

Naval service

No significant events.
