Vladimirets 2000

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
МПК-215 [MPK-215]		501	More, Feodosia	17.4.1982	8.8.1987	31.12.1987	stricken 5.2001
МПК-220 [MPK-220], 4.1998- Владимирец [Vladimirets]		502	More, Feodosia	12.5.1984	20.8.1990	30.12.1990	stricken 2014
МПК-231 [MPK-231]		503	More, Feodosia	1989	---	---	suspended 1991

Technical data

Displacement standard, t	364
Displacement normal, t	470
Length, m	50.0
Breadth, m	9.89 deck 21.1 foils
Draught, m	2.16 hull 7.26 foils
No of shafts	3 twin propellers / 2 azipods
Machinery	501: 1 M10B + 1 M10D gas turbines (on outboard shafts), 1 M16 gas turbine (on central shaft) / 2 DRA-211 diesels (on azipods) others: 2 M10D gas turbine (outboard), 1 M16 gas turbine (central) / 2 DRA-211 diesels (on azipods)
Power, h. p.	501: 38000 (18000+20000)+8500=46500 / 2200 others: 40000+8500=48500 / 2200
Max speed, kts	60.5
Fuel, t	diesel oil
Endurance, nm(kts)	1230(12)
Armament	1 x 8 Strela-3 SAM (8 9M36), 1 x 1 - 176/59 AK-176, 1 x 6 - 30/54 AK-630M, 2 x 4 - 400 TT
Electronic equipment	MR-123-01 Vympel-A, MR-220 Reyd radar, Zvezda-M1-01, MGS-407K sonars, 2x PK-16 decoy RL
Complement	39

Standard scale images

Graphics

Project history

Development of Project 1141with stronger armament. Yard No 504 was cancelled.

Modernizations

None.

Naval service

No significant events.
