Razvedchik 1905

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Дозорный [Dozornyy]			Crichton, Abo	1903	1904	1905	dispatch vessel 4.1906, minesweeper 11.1919, TS 1.1928, re-commissioned as guard ship 12.1939, test ship 6.1940
Разведчик [Razvedchik], 8.1944- Т-31 [T-31]			Crichton, Abo	1903	1904	1905	dispatch vessel 4.1906, minesweeper 11.1919, dispatch vessel 5.1925, test ship 1937, re-commissioned as guard ship 12.1939, test ship 6.1940, guard ship 6.1941, minesweeper 7.1942, survey vessel 2.1948

Technical data

Displacement normal, t	100
Displacement full, t
Length, m	30.8
Breadth, m	5.00
Draught, m	1.70
No of shafts	1
Machinery	1 VTE, 2 boilers
Power, h. p.	660
Max speed, kts	16
Fuel, t	coal
Endurance, nm(kts)	960(10)
Armament	1 x 1 - 37/20 Hotchkiss, 2 x 1 - 7.6/94
Complement	31

Standard scale images

Graphics

Project history

Former escorts of emperor`s yachts.

Modernizations 11.

1919, both: + mechanical minesweeping gear

1925, Razvedchik; 1928, Dozornyy: - minesweeping gear

1939, both: - 1 x 1 - 37/20; + 2 x 1 - 45/43 21K

1940, both: disarmed

1941, Razvedchik: + 2 x 1 - 45/43 21K, 2 x 1 - 7.6/94

1942, Razvedchik: + mechanical minesweeping gear

Naval service

In 1919-1922 they were used as minesweepers. Razvedchik in 1937 was disarmed and converted to test ship. 24.6.1941 she was armed and converted to guard ship.
