Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
ПВО-10 [PVO-10] ПВО-11 [PVO-11], 4.1944- КАТЩ-224 [KATShch-224], 6.1944- KT-224 ПВО-12 [PVO-12] ПВО-13 - 15 [PVO-13 - 15], 4.1944- КАТЩ-225 - 227 [KATShch-225 - 227] ПВО-16 - 19 [PVO-16 - 19], 4.1944- КАТЩ-228 - 231 [KATShch-228 - 231], 6.1944- KT-228 - 231 ПВО-20 - 22 [PVO-20 - 22] ПВО-23 [PVO-23], 4.1944- КАТЩ-233 [KATShch-233], 6.1944- KT-233 ПВО-24 [PVO-24] ПВО-25 [PVO-25], 4.1944- КАТЩ-234 [KATShch-234], 6.1944- KT-234 ПВО-26 [PVO-26] ПВО-27 [PVO-27] ПВО-61 - 68 [PVO-61 - 68] ПВО-69 [PVO-69], 9.1945- MK-116 ПВО-70 [PVO-70], 9.1945- MK-117 ПВО-71 - 80 [PVO-71 - 80]	343 Yd, Gorokhovets: PVO10-27, 61-80	1943: PVO-10 - 27 1944: PVO-61 - 80	PVO-10 (17.11.1943), PVO-12 (21.11.1943), PVO-20 (21.11.1943), PVO-21 (10.1.1944), PVO-22 (21.11.1943), PVO-24 (26.11.1943), PVO-26 (15.11.1943), PVO-27 (23.11.1943)	none	1945: KT-224, 228, 234 1947 - 1948: KATShch-225 - 227, KT-229 - 231, 233, PVO-61 - 68, MK-116, 117, PVO-71 - 80

Technical data

Displacement standard, t	15.5
Displacement full, t	18.9
Length, m	14.6
Breadth, m	3.57
Draught, m	0.85
No of shafts	1
Machinery	1 Chrysler petrol engine
Power, h. p.	115
Max speed, kts	8
Fuel, t	petrol 0.9
Endurance, nm(kts)	150(4.5)
Armament	1 x 1 - 37/63 70K, 1 x 1 - 20/70 Oerlikon Mk IV or 1 x 1 - 12.7/79
Complement	13

Standard scale images

Graphics

Project history

AA launches built on the basis of construction of landing boat project 165.

Modernizations 4.

1944, KATShch-224 - 231, 233, 234: - 1 x 1 - 37/63, 1 x 1 - 20/70; + 1 x 1 - 7.6/94, mechanical minesweeping gear.

9/1945, MK-116, 117: - 1 x 1 - 37/73; + 1 x 24 - 82 M-8 RL

Naval service

No significant events.
