SAKHALIN border guard ships (project 745P) (1974-2006)
Chukotka 2008
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| Сахалин [Sakhalin] | 185 | 405 | Yaroslavl SYd | 1974 | 31.12.1974 | in service (2019) | |
| Камчатка [Kamchatka] | 406 | Yaroslavl SYd | 6.12.1975 | stricken 9.2017 | |||
| Амур [Amur] | 408 | Yaroslavl SYd | 24.1.1977 | wrecked 22.11.2007 | |||
| Брест [Brest] | 106 | 410 | Yaroslavl SYd | 5.2.1978 | in service (2019) | ||
| Ладога [Ladoga] | 412 | Yaroslavl SYd | 29.10.1978 | stricken 10.2016 | |||
| Приморье [Primorye] | 172 | 413 | Yaroslavl SYd | 15.1.1978 | in service (2019) | ||
| Забайкалье [Zabaykalye] | 196 | 415 | Yaroslavl SYd | 1981 | in service (2019) | ||
| Ян Берзин [Yan Berzin], 1994- Байкал [Baykal] | 105 | 416 | Yaroslavl SYd | 30.9.1980 | in service (2019) | ||
| Чукотка [Chukotka] | 011 | 419 | Yaroslavl SYd | 14.2.1982 | in service (2019) | ||
| Заполярье [Zapoliarye] | 038 | 420 | Yaroslavl SYd | 29.9.1982 | in service (2019) | ||
| Карелия [Kareliya] | 103 | 423 | Yaroslavl SYd | 29.12.1983 | in service (2019) | ||
| Неман [Neman] | 425 | Yaroslavl SYd | 19.10.1984 | wrecked 16.6.1996 | |||
| Буг [Bug] | 142 | 427 | Yaroslavl SYd | 1985 | 8.1985 | 25.11.1985 | in service (2019) |
| Урал [Ural] | 016 | 428 | Yaroslavl SYd | 30.9.1986 | in service (2019) | ||
| Енисей [Yenisey], later- Тверь [Tver'] | 022 | 431 | Yaroslavl SYd | 5.11.1987 | in service (2019) | ||
| Виктор Кингисепп [Viktor Kingisepp] | 035 | 432 | Yaroslavl SYd | 30.9.1988 | in service (2019) | ||
| Таймыр [Taymyr], 1.2000- Генерал армии Матросов [General Armii Matrosov] | 551 | 439 | Yaroslavl SYd | 3.6.1992 | 1992 | in service (2019) | |
| Дон [Don] | 353 | 440 | Yaroslavl SYd | 18.12.1991 | 8.1996 | 24.10.1997 | in service (2019) |
| Якутия [Yakutiya], 2006- Магаданец [Magadanets] | 044 | 441 | Yaroslavl SYd | 5.1997 | 11.10.2005 | 28.5.2006 | in service (2019) |
Technical data
| Displacement standard, t | 1210 |
|---|---|
| Displacement full, t | 1620 |
| Length, m | 56.5 |
| Breadth, m | 12.6 |
| Draught, m | 4.60 |
| No of shafts | 1 |
| Machinery | 2 PG-950 electric motors, 2 DGR-1000/750 diesel-generators |
| Power, h. p. | 3000 |
| Max speed, kts | 13 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 8000(11) |
| Armament | 405-428: 2 x 2 - 30/71 AK-230M 431-441: 2 x 6 - 30/54 AK-306 |
| Electronic equipment | 2x Don radars |
| Complement | 47 |
Standard scale images
Sakhalin 2000
Graphics
Chukotka 2008
Project history
Border Guard patrols, built in hulls of seagoing tugs.
Modernizations
2010s, General Armii Matrosov, Baykal: + MR-212/201 Vaygach-U radar
2010s, Brest, Sakhalin: + Liman-18 radar
2010s, Baykal: + MR-3PV Liman-18M1 radar
2010s, Brest: + Nayada-25 radar
2010s, Baykal: + MR-415.4 Poisk radar
2010s, Viktor Kingisepp, Don, Zabaykalye, Zapoliarye, Kamchatka, Kareliya, Ural, Baykal, Magadanets: + MR-231 radar
2010s, Primorye, Sakhalin: + Furuno 1525 radar
2010s, Bug: + Nayada-25M1 radar
2010s, Zabaykalye: + Baltika-M radar
2010s, Primorye: + JMA-7710 radar
2010s, Don: + MR-212/201-3 radar
2010s, Kareliya: + MR-212 radar
2013, Zabaykalye: - Baltika-M radar; + MR-415 Poisk radar
2015, General Armii Matrosov: - MR-212/201 Vaygach-U radar; + MR-231 radar
Naval service
Neman 16.6.1996 ran ashore in Dimitrov Bight and later demolished by the storm waves. Amur 22.11.2007 drifted ashore on the anchor and wrecked in Kuybyshevskiy Bay (Iturup Island, Kuriles).
