Retriever 2003

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
81 Rescuer 82 Retriever	More, Feodosiya, USSR: 81, 82	1989: 81, 82	none	none	in service (2020): 81, 82

Technical data

Displacement standard, t	37
Displacement full, t	40
Length, m	23.8
Breadth, m	5.15
Draught, m	1.00
No of shafts	2
Machinery	2 M-401BT diesels
Power, h. p.	2000
Max speed, kts	29
Fuel, t	diesel oil
Endurance, nm(kts)	450(13)
Armament	2 x 2 - 12.7/79
Electronic equipment	Lotsiya radar
Complement	14

Standard scale images

Graphics

Project history

Soviet export project 1400ME.

Modernizations

2003, Rescuer: diesels were replaced by 2 Caterpillar 3406E (1600hp, 24kts, 350(10)nm); - Lotsiya radar; + Furuno radar

2009, Retriever: diesels were replaced by 2 Caterpillar C18 (1746hp, 24kts, 350(10)nm); - Lotsiya radar; + Furuno radar

Naval service

No significant events.
