NAVYPEDIA


Amar 1976

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Amar (ex-अमर [Amar])	P1		Hooghly, Calcutta, India			1961 // 4.1974	stricken 1997

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate Amar (ex-अमर [Amar]) P1   Hooghly, Calcutta, India     1961 // 4.1974 stricken 1997

Technical data

Displacement standard, t	120
Displacement full, t	160
Length, m	33.5 pp 35.7 oa
Breadth, m	6.10
Draught, m	1.50
No of shafts	3
Machinery	2 12-cyl Paxman diesels + 1 Foden diesel
Power, h. p.	1100 + 100
Max speed, kts	18 / 8
Fuel, t	diesel oil 23
Endurance, nm(kts)
Armament	1 x 1 - 40/60 Mk 7
Electronic equipment	type 978 radar
Complement	35

Standard scale images

Graphics

Project history

Former Indian Ajay-class (variant of British Ford) patrol boat. Transferred without ASW equipment.

Modernizations

None.

Naval service

No significant events.
