Sagi

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
鴻 [Otori]			Maizuru K K	11/1934	25.4.1935	10.1936	sunk 12.6.1944
鵲 [Kasasagi]			Osaka Tekkosho, Osaka	3/1935	28.10.1935	1.1937	sunk 26.9.1943
鵯 [Hiyodori]			Ishikawajima, Tokyo	11/1934	25.10.1935	12.1936	sunk 17.11.1944
隼 [Hayabusa]			Yokohama Co, Yokohama	12/1934	28.10.1935	12.1936	sunk 24.9.1944
鳩 [Hato]			Ishikawajima, Tokyo	5/1936	25.1.1937	8.1937	sunk 16.10.1944
鷺 [Sagi]			Harima Co, Harima	5/1936	30.1.1937	7.1937	sunk 8.11.1944
雁 [Kari]			Mitsubishi, Yokohama	5/1936	20.1.1937	9.1937	sunk 16.7.1945
雉 [Kiji]			Tama, Okayama	10/1935	26.1.1937	7.1937	surrendered 8.1945, to Soviet Union 10.1947 (Внимательный [Vnyimatyelnyy])

Technical data

Displacement standard, t	840
Displacement full, t	1040
Length, m	85.0 pp 86.8 wl 88.5 oa
Breadth, m	8.18
Draught, m	2.76
No of shafts	2
Machinery	2 sets Kampon geared steam turbines, 2 Kampon boilers
Power, h. p.	19000
Max speed, kts	30.5
Fuel, t	oil 150
Endurance, nm(kts)	4000(14)
Armament	3 x 1 - 120/45 11-shiki, 1 x 1 - 40/62 HI 91-shiki, 1 x 3 - 533 TT, 2 DCT
Complement	113

Standard scale images

Graphics

Project history

On torpedo boats of this class errors supposed at designing of Tomozuru have been corrected: armament was moderated and changes were made to construction of superstructures. For stability raise the hull beam was increased. Displacement and draught were increased. At the expense of growth of engine power (on 72%) designed speed has raised. Armament repeated fitted on Tomozuru after reconstruction. They were ordered as numbers 5-20 under 2nd Supplementary programme of 1934, but building of eight of 16 planed ships was cancelled in favour of building of submarine chasers. No13-20 (Hatsutaka, Aotaka, Wakataka, Kumataka, Yamadori, Mizudori, Umidori and Komadori) were never ordered.

Modernizations

1942, all: - 1 x 1 - 120/45, 1 x 1 - 40/62; + 2 x 2 - 25/60 96-shiki, 2 DCT (48 totally)

1944, all survived: + 1 x 2 - 25/60 96-shiki, 5 x 1 - 25/60 96-shiki, 3-shiki 1-go radar, standard displacement increased to 1043t.

Naval service

Kasasagi 26.9.1943 was sunk in Flores Sea by US submarine Bluefish. Otori 12.6.1944 was sunk NE off Saipan by US carrier aircraft. Hayabusa 24.9.1944 was sunk SE off Manila by US carrier aircraft. Hato 16.10.1944 was sunk SE off Hong Kong by US carrier aircraft. Sagi 8.11.1944 was sunk W off Luzon by US submarine Gunnel. Hiyodori 17.11.1944 was sunk at E Coast of Luzon by US submarine Gunnel. Kari 16.7.1945 was sunk in 220nm SW off Macassar (Celebes) by US submarine Вауа. Kiji in October, 1947 was transferred to USSR on reparation.
