SATSUKI destroyer (1902 / 1905)





Satsuki

Ships


Name No Yard No Builder Laid down Launched Comp Fate
皐月 [Satsuki] (ех-Бедовый [Bedovyy])     Nevskiy Wks, St. Petersburg, Russia 1900 4.5.1902 10/1902 // 6.1905 target 1913


Technical data


Displacement normal, t350
Displacement full, t

480
Length, m

64.0
Breadth, m

6.40
Draught, m

2.59 max
No of shafts

2
Machinery

2 VTE, 4 Yarrow boilers
Power, h. p.

5700
Max speed, kts

26
Fuel, t

coal 80
Endurance, nm(kts)1200(12)
Armament

1 x 1 - 75/48 Canet, 5 x 1 - 47/40 3pdr Hotchkiss, 1 - 381 TT (bow), 2 x 1 - 381 TT
Complement

75


Standard scale images


<i>Satsuki</i> 1905
Satsuki 1905


Graphics


<i> Satsuki</i>
Satsuki


Project history

Russian destroyer of Laird design, captured 28.5.1905 by destroyers Sazanami and Kagero S of Uldshin after Tsushima battle.

Modernizations

1905: - 1 - 381 TT (bow)

1906: - 1 x 1 - 75/50, 2 x 1 - 381 TT; + 2 x 1 - 450 TT; old boilers were replaced by 4 Miyabara.

Naval service

Used as target until 1922.
