1971 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Wolgast, later- Schwedt	501/650	113	Peenewerft, Wolgast			10.4.1964	stricken 2.1978
Eisenhüttenstadt	502/618	137	Peenewerft, Wolgast			20.5.1964	stricken 10.1978
Grimmen	503/619	138	Peenewerft, Wolgast			20.5.1964	stricken 10.1978
Lübben	504/616	139	Peenewerft, Wolgast			15.8.1964	stricken 11.1976
Hoyerswerda	505/619	140	Peenewerft, Wolgast			15.8.1964	stricken 8.1975
Eberswalde/Finow	506/614	141	Peenewerft, Wolgast			20.10.1964	stricken 11.1976

Technical data

Displacement standard, t	709
Displacement full, t	1260
Length, m	64.0
Breadth, m	11.6
Draught, m	2.48
No of shafts	2
Machinery	2 40DM diesels
Power, h. p.	4400
Max speed, kts	14
Fuel, t	diesel oil
Endurance, nm(kts)	1400(10)
Armament	1 x 2 - 57/75 ZIF-31B, 2 x 2 - 25/80 2M-3
Military load	7 medium tanks or 500 t of cargo
Electronic equipment	KSA-3 radar
Complement	24

Standard scale images

Graphics

Project history

 Medium landing ships of domestic design.

Modernizations

1970s, all: - KSA-3 radar; + TSR-333 radar

Naval service

: No significant events.
