Nordperd 1989 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp.	Fate
Nordperd	E-35/E-171	109.01	Peenewerft, Wolgast, East Germany	26.1.1978	30.8.1978	3.10.1979	stricken 10.1990, to Indonesia (Teluk Cirebon)
Südperd	E-36/E-172	109.02	Peenewerft, Wolgast, East Germany	16.4.1978	30.10.1978	26.2.1980	stricken 10.1990, to Indonesia (Teluk Sabang)

Technical data

Displacement standard, t	1744
Displacement full, t	1950
Length, m	90.7
Breadth, m	11.1
Draught, m	2.80 mean 3.40 max
No of shafts	2
Machinery	2 61B diesels
Power, h. p.	12000
Max speed, kts	18
Fuel, t	diesel oil
Endurance, nm(kts)	2450(14)
Armament	1 x 4 Fasta-4M SAM (16 9M32M), 2 x 2 - 57/50 AK-725, 2 x 2 - 25/82 2M-3M
Military load	650 t cargo or mines
Electronic equipment	TSR-333, MR-302 Rubka, MR-105 Bars radars, 2x PK-16 decoy RL
Complement	35

Standard scale images

Graphics

Project history

Project 109, armed support ships on base of project 108 landing ships with the combat outfit reduced but with a 8t crane amidships.

Modernizations

None.

Naval service

No significant events.
