NAVYPEDIA


Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Grevesmühlen	461/212	142	Peenewerft, Wolgast		8.8.1964	7/1965	stricken 10.1983
Gadebusch	421/211	143	Peenewerft, Wolgast			7/1965	stricken 8.1983
Wismar	422/214	144	Peenewerft, Wolgast			7/1965	stricken 5.1980
Sternberg	423/215	145	Peenewerft, Wolgast			7/1965	stricken 2.1984
Parchim	424/213	146	Peenewerft, Wolgast			7/1965	stricken 10.1980
Ludwigslust	431/215	147	Peenewerft, Wolgast			12/1965	stricken 11.1982
Perleberg	414/241	148	Peenewerft, Wolgast			1/1966	stricken 4.1981
Bad Doberan	451/242	149	Peenewerft, Wolgast			1/1966	stricken 12.1981
Bützow	452/243	165	Peenewerft, Wolgast			7/1966	stricken 7.1981
Lübz	433/244	166	Peenewerft, Wolgast			7/1966	stricken 10.1981
Ribnitz-Damgarten	453/214	167	Peenewerft, Wolgast			7/1966	stricken 6.1983
Teterow	454/213	168	Peenewerft, Wolgast			1/1967	stricken 1.1983

Technical data

Displacement standard, t
Displacement full, t	320
Length, m	51.7
Breadth, m	6.60
Draught, m	2.58
No of shafts	3
Machinery	2 Pirna 014 gas turbines + 1 40D diesel
Power, h. p.	9860 + 2000 = 11860
Max speed, kts	32
Fuel, t	diesel oil
Endurance, nm(kts)	1000(18)
Armament	2 x 2 - 30/71 AK-230, 2 x 5 RBU-1200 ASWRL, 2 DCR
Electronic equipment	Reya, Rys' radars, Tamir-11 sonar
Complement	29

Standard scale images

Graphics

Project history

 'Hai III' class. Gas turbines used only for short bursts of hunting speed.

Modernizations

None.

Naval service

: No significant events.
