NAVYPEDIA


Fritz Globig 1988 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Albin Köbis	771, 1987- 571	01713	Vympel, Rybinsk, USSR			31.10.1984	stricken 10.1990
Rudolf Eglhofer	772, 1987- 572	01714	Vympel, Rybinsk, USSR			16.1.1985	reunification 10.1990 (Hiddensee), stricken 1991
Fritz Globig (ex-Р-615 [R-615])	773, 1987- 573	01715	Vympel, Rybinsk, USSR			5.10.1985	stricken 10.1990
Paul Eisenschneider	774, 1987- 574	01716	Vympel, Rybinsk, USSR			12.2.1986	stricken 10.1990
Hans Beimer (ex-Р-630 [R-630])	775, 1987- 575	01717	Vympel, Rybinsk, USSR			28.10.1986	stricken 10.1990

Technical data

Displacement standard, t	385
Displacement full, t	455
Length, m	56.1
Breadth, m	10.2
Draught, m	2.20
No of shafts	2
Machinery	COGAG: 2 M-15E gas turbine units (each consist of M-75 cruising gas turbine and M-70 boost gas turbine)
Power, h. p.	10000 + 24000 = 34000
Max speed, kts	43
Fuel, t	diesel oil
Endurance, nm(kts)	2200(14)
Armament	2 x 2 P-20M Termit SSM (4 P-20M), 1 x 4 Strela-3M SAM (12 9M36M), 1 x 1 - 76/59 AK-176M, 2 x 6 - 30/54 AK-630M
Electronic equipment	Garpun-E, MR-123 Vympel-A, Kivach-2 radars, Vympel-R2 ECM suite, 2x PK-16 decoy RL
Complement	41

Standard scale images

Graphics

Project history

Former Soviet Project 1241RE FAC (missile).

Modernizations

None.

Naval service

: No significant events.
