XXXIV

Ships

Names	Builders	Completed	Losses	Transfers	Discarding
XXXIV - XXXIX, 1910- 44 - 49	Schichau, Elbing, Germany: XXXIV Marinearsenal Pola: XXXV - XXXIX	1889: XXXIV 1891: XXXV - XXXIX	none	none	1911: 44, 46 - 48 1913: 49 8/1914: 45

Technical data

Displacement normal, t	64
Displacement full, t
Length, m	36.9 wl
Breadth, m	4.80
Draught, m	1.90
No of shafts	1
Machinery	1 VC, 1 locomotive boiler
Power, h. p.	750
Max speed, kts	20.3
Fuel, t	coal
Endurance, nm(kts)
Armament	2 x 1 - 37/20 SFK L/23 H, 1 - 356 TT (bow), 1 x 1 - 356 TT
Complement	16

Standard scale images

Graphics

Project history

II class, D-type.

Modernizations

1907, XXXVII, XXXVIII; 1908, XXXIV-XXXVI, XXXIX: - 1 x 1 - 356 TT

Naval service

No significant events.
