Adler Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Adler, 1910- 41		694	Yarrow, Poplar, UK	1884	12/1884	1886	stricken 1911
Falke, 1910- 42		693	Yarrow, Poplar, UK	1884	12/1884	1886	stricken 1911

Technical data

Displacement normal, t	95
Displacement full, t	100
Length, m	41.2
Breadth, m	4.20
Draught, m	1.70
No of shafts	1
Machinery	1 VC, 2 locomotive boilers
Power, h. p.	1300
Max speed, kts	22
Fuel, t	coal
Endurance, nm(kts)
Armament	2 x 1 - 37/20 SFK L/23 H, 2 - 356 TT (bow)
Complement	16

Standard scale images

Graphics

Project history

Original design became prototype for British TB80.

Modernizations

None.

Naval service

No significant events.
