BIOKOVO patrol boats (1981-1985)
Pohorje 1988
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| Биоково [Biokovo] | ПЧ171 [PCh171] | Tito, Kraljevica | 18.12.1980 | 1981 | captured by Croatia 9.1991 (Novigrad) | ||
| Похорjе [Pohorje] | ПЧ172 [PCh172] | Tito, Kraljevica | 1981 | to Montenegro 2006 (Pohorje) | |||
| Копривник [Koprivnik] | ПЧ173 [PCh173] | Tito, Kraljevica | 1981 | to Montenegro 2006 (Koprivnik) | |||
| Учка [Učka], 2005- Бар [Bar] | ПЧ174 [PCh174], 2005- П01 [P01] | Tito, Kraljevica | 1982 | Naval police 2005, to Montenegro 2006 (Bar) | |||
| Грмеч [Grmeč] | ПЧ175 [PCh175] | Tito, Kraljevica | 1982 | to Montenegro 2006 (Grmeč) | |||
| Мукос [Mukos] | ПЧ176 [PCh176] | Tito, Kraljevica | 11.11.1982 | 1983 | captured by Croatia 1991 (Šolta) | ||
| Фрушка Гора [Fruška Gora] | ПЧ177 [PCh177] | Tito, Kraljevica | 1983 | to Montenegro 2006 (Fruška Gora) | |||
| Космаj [Kosmaj], 2005- Херцег Нови [Herceg Novi] | ПЧ178 [PCh178], 2005- П03 [P03] | Tito, Kraljevica | 1983 | Naval police 2005, to Montenegro 2006 (Herceg Novi) | |||
| Зеленгора [Zelengora] | ПЧ179 [PCh179] | Tito, Kraljevica | 1983 | to Montenegro 2006 (Zelengora) | |||
| Цер [Cer] | ПЧ180 [PCh180] | Tito, Kraljevica | 27.9.1984 | 1984 | captured by Croatia 1991 (Cavtat) | ||
| Дурмитор [Durmitor] | ПЧ181 [PCh181] | Tito, Kraljevica | 10.1.1985 | 1985 | captured by Croatia 1991 (Hrvatska Kostajnica) |
Technical data
| Displacement standard, t | 125 |
|---|---|
| Displacement full, t | 142 |
| Length, m | 29.3 pp 32.0 oa |
| Breadth, m | 6.68 |
| Draught, m | 1.76 hull 2.41 max |
| No of shafts | 2 |
| Machinery | 2 SEMT-Pielstick 12PA4200GDS diesels |
| Power, h. p. | 6000 |
| Max speed, kts | 30 |
| Fuel, t | diesel oil 16 |
| Endurance, nm(kts) | 400(20) |
| Armament | 1 x 4 Fasta-4M SAM (8 9K32), 1 x 1 - 40/70 Bofors 315, 1 x 1 - 20/90 M-71, 8 DC |
| Electronic equipment | Decca 1216C radar, SQS-3D/SF sonar |
| Complement | 19 |
Standard scale images
Grmeč 1990
Graphics
Pohorje 1988
Project history
Type140, built as replacement for 'Type 131' in commission with naval border detachments. Fitted with additional outboard electric motor for quiet operation, capable to make 6kts speed.
Modernizations
2005, Bar, Herceg Novi: - 1 x 4 Fasta-4M SAM, 1 x 1 - 40/70, 8 DC, SQS-3D/SF sonar
Naval service
No significant events.
