Tariq 1980

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
إل ملك فروق  [El Malek Farouq] (ex-Whimbrel), 1956-  طارق [Tariq]	42, 1978- 555, 1983- 931		Yarrow, Scotstoun, UK	10.1941	25.8.1942	1.1943 // 11.1949	accommodation vessel mid-1980s, TS late 1980s, stricken 2003

Technical data

Displacement standard, t	1490
Displacement full, t	1950
Length, m	86.3 pp 91.3 oa
Breadth, m	11.7
Draught, m	3.40 - 3.50 deep load
No of shafts	2
Machinery	2 sets Parsons geared steam turbines, 2 Admiralty 3-drum boilers
Power, h. p.	4300
Max speed, kts	19.75
Fuel, t	oil 420
Endurance, nm(kts)	9200(10)
Armament	3 x 2 - 102/45 Mk XIX, 2 x 2 - 40/60 Mk V, 2 x 2 - 20/70 Mk V, 2 x 1 - 20/70 Mk III, 8 DCT, 2 DCR (110)
Electronic equipment	type 271, type 291 radars, type 144 sonar
Complement	192

Standard scale images

Graphics

Project history

Modified British Black Swan frigate, purchased by Egypt.

Modernizations

None.

Naval service

Since mid-1980s Tariq served as accommodation hulk but relegated to training service in late 1980s.
