Kotor 1998

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Котор [Kotor]	ВПБР33 [VPBR33], 1993- ФР33 [FR33]		Tito SY, Kraljevica	1981	21.5.1985	1/1987	to Montenegro 2006 (Kotor)
Пула [Pula], 1993- Нови Сад [Novi Sad]	ВПБР34 [VPBR34], 1993- ФР34 [FR34]		Tito SY, Kraljevica	1982	18.12.1986	11/1988	to Montenegro 2006 (Novi Sad)

Technical data

Displacement standard, t	1492
Displacement full, t	1850
Length, m	91.8 wl 96.7 oa
Breadth, m	11.7
Draught, m	3.55 hull 5.80 sonar
No of shafts	3
Machinery	CODAG: 1 M-8G gas turbine + 2 SEMT-Pielstick 12PA6V280 diesels
Power, h. p.	19000+9600=28600
Max speed, kts	27
Fuel, t	diesel / gas turbine oil
Endurance, nm(kts)	1800(14)
Armament	2 x 2 P-21 Termit SSM (4 P-21), 1 x 2 Osa-M SAM (20 9M33), 2 x 4 Fasta-4M SAM (16 9K32), 1 x 2 - 76/59 AK-726, 2 x 2 - 30/71 AK-230, 2 x 1 - 20/90 M-71, 2 x 12 RBU-6000 Smerch-2 ASWRL
Electronic equipment	MR-302 Rubka, MR-212 Vaygach, 4R-33, 9LV200 Mk 1, MR-104 Rys' radars, MG-322T sonar, J-2150 ECM suite, 2x Barricade decoy RL
Complement	107

Standard scale images

Graphics

Project history

Designed in Yugoslavia on the basis of Soviet project 1159. Ships have mixed Soviet/Western machinery, Soviet armament and mixed electronics. Planned triple 324mm ILAS3 TT for Italian A244 torpedoes were never installed.

Modernizations

2000, Kotor; 2016, Novi Sad: + CCS

Naval service

No significant events.
