AGILE coastal minesweepers (1941)
Affray 1942
Ships
| No | Name | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| AMc111 | Agile | Petersen SB, Tacoma | 1940 | 1941 | 12.1941 | miscellaneous auxiliary IX203 12.1944 | |
| AMc112 | Affray | Tacoma Boat | 1940 | 1941 | 12.1941 | stricken 1.1946 |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 215 |
| Length, m | 29.3 |
| Breadth, m | 7.32 |
| Draught, m | 2.13 |
| No of shafts | 1 |
| Machinery | 1 Atlas diesel |
| Power, h. p. | 275 |
| Max speed, kts | 10 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | |
| Armament | 2 x 1 - 12.7/90, 2 x 1 - 7.6/90, mechanical minesweeping gear |
| Complement | 17 |
Graphics
Affray 1942
Project history
Wooden-hulled trawlers, purchased by the USN before completing.
Modernizations
None.
Naval service
No significant events.
