LCVP MPF UB-40 landing craft (2006-2011)





2010

Ships


Names Builders Commissioned Losses Transfers Discarding

LCVP1953 - 1986

Kvichak Marine Industries, Seattle: 33 boats

2006: 26 boats

2011: 5 boats

none

none

in service (2019): 33 boats


Technical data


Displacement standard, t12
Displacement full, t18
Length, m

12.2 pp 13.4 oa

Breadth, m

4.42

Draught, m

0.76

No of shafts2 waterjets
Machinery2 Cummins QSM 11 diesels
Power, h. p.660
Max speed, kts

41 (30 full load)

Fuel, tdiesel oil
Endurance, nm(kts)
Armament3 x 1 - 7.6/90
Military load30 troops or 4.5t of cargo
Electronic equipmentFuruno radar
Complement3


Graphics


2010
2010


Project history

Landing Craft, Vehicle and Personnel, Maritime Prepositioning Force Utilty Boat. Aluminium construction, single hinged bow door.

Modernizations

None.

Naval service

No significant events.
