3! PAYSANDÚ coastal patrol craft (1969)
Paysandú 1975
Ships
| Names | Builders | Completed | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
PR12 Paysandú |
Sewart Seacraft, Morgan City, USA: PR12 |
1969: PR12 |
None |
None |
in service (20199): PR12 |
Technical data
| Displacement standard, t | 44 |
|---|---|
| Displacement full, t | 54 |
| Length, m | 25.9 |
| Breadth, m | 5.69 |
| Draught, m | 2.10 |
| No of shafts | 2 |
| Machinery | 2 General Motors 16V71N diesels |
| Power, h. p. | 1400 |
| Max speed, kts | 22 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 800(21) |
| Armament | 3 x 1 - 12.7/90 |
| Electronic equipment | Raytheon 1500B Pathfinder radar |
| Complement | 8 |
Graphics
Paysandú 1975
Project history
US 85ft Commercial Cruiser type, built under MDAP. Aluminium hull.
Modernizations
None.
Naval service
No significant events.
