PC69 1918
PC74 1939
| Name | No | Builder | Laid down | Launched | Comp | Fate |
| PC42 | Caird, Greenock | 1916 | 7/6/1917 | 1917 | BU 12/1921 | |
| PC43 | Caird, Greenock | 1916 | 14/8/1917 | 1917 | BU 1/1923 | |
| PC44 | Eltringham, Willington Quay | 1916 | 25/4/1917 | 1917 | BU 4/1923 | |
| PC51 | Tyne Iron Wks, Willington Quay | 1916 | 25/11/1916 | 1917 | sold 1/1923 | |
| PC55, 5/1922- Baluchi (3/1922 - RIM) | Barclay Curle, Glasgow | 1916 | 5/5/1917 | 1917 | BU 1935 | |
| PC56 | Barclay Curle, Glasgow | 1916 | 2/6/1917 | 1917 | BU 7/1923 | |
| PC60 | Workman Clark, Belfast | 1916 | 4/6/1917 | 1917 | BU 2/1924 | |
| PC61 | Workman Clark, Belfast | 1916 | 19/6/1917 | 1917 | BU 4/1923 | |
| PC62 | Harland & Wolff, Govan | 1916 | 7/6/1917 | 8/1917 | BU 12/1921 | |
| PC63 | Connell, Scotstoun | 1916 | 2/10/1917 | 12/1917 | BU 5/1923 | |
| PC65 | Eltringham, Willington Quay | 1917 | 5/9/1917 | 1917 | sold 1/1923 | |
| PC66 | Harkness, Middlesbrough | 1917 | 12/2/1918 | 1918 | BU 7/1923 | |
| PC67 | White, Cowes | 1917 | 7/5/1917 | 6/1917 | BU 12/1921 | |
| PC68 | White, Cowes | 1917 | 29/6/1917 | 6/1917 | BU 12/1921 | |
| PC69, 5/1922- Pathan (8/1921 - RIM) | Workman Clark, Belfast | 1917 | 11/3/1918 | 1918 | internal explosion 23/6/1940 | |
| PC70 | Workman Clark, Belfast | 1917 | 12/4/1918 | 1918 | BU 9/1926 | |
| PC71 | White, Cowes | 1917 | 18/3/1918 | 5/1918 | BU 11/1925 | |
| PC72 | White, Cowes | 1917 | 8/6/1918 | 9/1918 | BU 10/1925 | |
| PC73, 4/1925- Dart | White, Cowes | 1917 | 1/8/1918 | 10/1918 | fishery protection vessel 4/1925, sold 2/1939 | |
| PC74 | White, Cowes | 1917 | 4/10/1918 | 12/1918 | decoy vessel Chatsgrove 9 - 10/1939, BU 7/1948 |
|
Displacement normal, t |
PC42 - 63: 682 PC65 - 74: 694 |
|
Displacement full, t |
780 |
|
Length, m |
75.3 |
|
Breadth, m |
PC42 - 63: 7.80 PC65 - 74: 8.20 |
|
Draught, m |
2.40 |
|
No of shafts |
2 |
|
Machinery |
Parsons or Brown-Curtis steam turbines, 2 Yarrow boilers |
|
Power, h. p. |
3500 |
|
Max speed, kts |
20 |
|
Fuel, t |
oil 164 |
|
Armament |
1 x 1 - 102/40 QF Mk I, 2 x 1 - 76/40 QF Mk I HA, 2 x 1 - 356 TT, 2 DCR (30) |
|
Complement |
50 - 55 |
Ship project history: These ships formed as purely anti-submarine, and, besides DCs and guns, in fighting with submarines the big role assigned drawing possibilities of a ramming blow (that was promoted by the long diving time of this time submarines) for what they had the strengthened stem and very good manoeuvrability. A part of the ships ("PC" type) was built outwardly masked under merchant vessels, i.e. as classical decoys ("Q"-ships).
Modernizations: 1930s, PC74: - 1 x 1 - 76/40, 2 x 1 - 356 TT
1930s, Baluchi, Pathan: - 1 x 1 - 76/40, 2 x 1 - 356 TT, 2 DCR
1940s, PC74: - 1 x 1 - 102/40; + 1 x 1 - 76/40 QF Mk I HA, 1 x 1 - 40/39 pompom, 1 x 1 - 20/70 Oerlikon
Naval service: Pathan (before transfer to RIM PC69) was lost 23/6/1940 at Bombay by the reason of internal explosion, by another version, she was sunk by Italian submarine Galvani on the approach to Persian gulf.
PC68
