Sakarya 1936

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Sakarya			CNT, Monfalcone, Italy	1/1930	5.2.1931	10/1931	stricken 1949

Technical data

Displacement standard, t
Displacement normal, t	815 / 1145
Length, m	61.6
Breadth, m	6.68
Draught, m	4.30
No of shafts	2
Machinery	2 MAN diesels / 2 electric motors
Power, h. p.	1500 / 1100
Max speed, kts	16.9 / 9.5
Fuel, t	diesel oil
Endurance, nm(kts)	4000(10) / 74(4)
Armament	1 x 1 - 100/43 OTO 1927, 6 - 533 TT (4 bow, 2 stern, 12)
Electronic equipment	presumably hydrophone
Complement	41
Diving depth operational, m	100

Standard scale images

Graphics

Project history

Ordered under the 1929 programme in Italy together with larger submarine Dumlupinar. Medium submarine, designed by A. Bernardis on basis of Italian submarine Argonauta from which differed in slightly increased dimensions caused by placing of more powerful engines for achievement of higher surfaced and submerged speeds. Single-hulled, with side blisters.    Sakarya and Dumlupinar departured from Monfalcone with mixed Italian-Turkish crews, arrived to Istanbul 5.11.1931 and commissioned next day.

Modernizations

mid-1940s: + 1 x 1 - 20/70 Oerlikon Mk IV.

Naval service

No significant events.
