FETH-ÜL İSLAM river monitors (1865)





Feth-ül İslam 1875

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Feth-ül İslam     F C de la Méditerranée, La Seyne, France 1864 1865 1865 stricken 1908
İşkodra     F C de la Méditerranée, La Seyne, France 1864 1865 1865 captured by Russia 16.7.1877 (Систово [Sistovo])
Böğürtlen     F C de la Méditerranée, La Seyne, France 1864 1865 1865 stricken 1880
Podgoriçe     F C de la Méditerranée, La Seyne, France 1864 1865 1865 captured by Russia 16.7.1877 (Никополь [Nikopol'])
Semendire, 1879- Memduhiye     F C de la Méditerranée, La Seyne, France 1864 1865 1865 stricken 1902


Technical data


Displacement normal, t335
Displacement full, t
Length, m31.5 oa 30.5 pp
Breadth, m9.80
Draught, m1.70
No of shafts2
Machinery2 1-cyl HSE, 2 rectangular boilers
Power, h. p.290
Max speed, kts8
Fuel, t

coal 20

Endurance, nm(kts)
Armour, mmiron; belt: 76, ends: 51, battery: 76, CT: 13
Armament2 x 1 - 160/16 Armstrong 64pdr MLR
Complement

50



Graphics


Feth-ül İslam 1875
Feth-ül İslam 1875


Project history

Original armoured ships built for Danube service. Iron-hulled central battery gunboats. The upper deck was only 48cm over wl.

Ship protection

Machinery was protected by 76mm belt, ship ends had 51mm protection. Battery had 76mm sides.

Modernizations

1871, all: + 6 x 1 - 76/18 Armstrong 9pdr 9cwt BL

1880, Memduhiye: was armed with 2 x 1 - 76/18 Armstrong 9pdr 9cwt BL

1884, Feth-ül İslam: - 2 x 1 - 160/16, 4 x 1 - 76/18; + 2 x 1 - 178/16 Armstrong 6.5-ton MLR

Naval service

İşkodra and Podgoriçe were captured by Russian troops at Nikopol 16.7.1877 and commissioned by Russian Navy as  Sistovo and Nikopol respectively. Feth-ül İslam was disarmed in 1901.
