NAVYPEDIA


Ç137 1980

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
	Ç107		Gölçuk SY, Kocaeli			1966-1973	stricken 1992
	Ç108		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç109		Gölçuk SY, Kocaeli			1966-1973	stricken 1985
	Ç110		Gölçuk SY, Kocaeli			1966-1973	stricken 1998
	Ç111		Gölçuk SY, Kocaeli			1966-1973	stricken 1981
	Ç112		Gölçuk SY, Kocaeli			1966-1973	stricken 1981
	Ç113		Gölçuk SY, Kocaeli			1966-1973	stricken 1992
	Ç114		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç115		Gölçuk SY, Kocaeli			1966-1973	stricken 1981
	Ç116		Gölçuk SY, Kocaeli			1966-1973	stricken 1981
	Ç117		Gölçuk SY, Kocaeli			1966-1973	stricken 2004
	Ç118		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç119		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç120		Gölçuk SY, Kocaeli			1966-1973	stricken 2012
	Ç121		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç122		Gölçuk SY, Kocaeli			1966-1973	stricken 2000
	Ç123		Gölçuk SY, Kocaeli			1966-1973	stricken 2013-14
	Ç124		Gölçuk SY, Kocaeli			1966-1973	stricken 2004
	Ç125		Gölçuk SY, Kocaeli			1966-1973	stricken 2013-14
	Ç126		Gölçuk SY, Kocaeli			1966-1973	stricken 2013-14
	Ç127		Gölçuk SY, Kocaeli			1966-1973	stricken 2013-14
	Ç128		Gölçuk SY, Kocaeli			1966-1973	stricken 2013-14
	Ç129		Gölçuk SY, Kocaeli			1966-1973	stricken 2006
	Ç130		Gölçuk SY, Kocaeli			1978	stricken 1983, to Lybia 12.1979 (القبيات [Al Qoubaiyat])
	Ç131		Gölçuk SY, Kocaeli			1978	stricken 1983, to Lybia 12.1979 (رئس الحلل [Rais El Hilel])
	Ç132		Gölçuk SY, Kocaeli			1980	in service (2019)
	Ç133		Gölçuk SY, Kocaeli			1980	stricken 2013-14
	Ç134		Gölçuk SY, Kocaeli			1980	stricken 2013-14
	Ç135		Gölçuk SY, Kocaeli			1980	stricken 2013-14
	Ç136		Gölçuk SY, Kocaeli		21.3.1980	20.7.1981	foundered 30.1.1985
	Ç137		Gölçuk SY, Kocaeli		21.3.1980	20.7.1981	stricken 2013-14
	Ç138		Taşkizak NSY, Istanbul		1984	1984	in service (2019)

Technical data

Displacement standard, t	260
Displacement full, t	580
Length, m	56.6
Breadth, m	11.6
Draught, m	1.25 aft
No of shafts	3
Machinery	3 General Motors Detroit 6-71 diesels
Power, h. p.	900
Max speed, kts	10
Fuel, t	diesel oil
Endurance, nm(kts)	1100(8)
Armament	2 x 1 - 20/70 Mk 10, 2 x 1 - 12.7/90
Military load	5 medium tanks, 100 troops
Electronic equipment	Decca TM1226 radar
Complement	17

Standard scale images

Graphics

Project history

Development of UK LCT(4) design.

Modernizations

None.

Naval service

Ç136 was lost in storm 31.1.1985.
