NAVYPEDIA


Sivrihisar 1979

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Sultanhisar	P111		Gunderson, Portland, USA	1963	1964	5.1964	stricken 11.2000
Demirhisar	P112		Gunderson, Portland, USA	1963	9.7.1964	4.1965	stricken 11.2000
Yarhisar	P113		Gunderson, Portland, USA	3.1963	14.5.1964	9.1964	stricken 2010
Akhisar	P114		Gunderson, Portland, USA	5.1963	14.5.1964	12.1964	stricken 2010
Sivrihisar	P115		Gunderson, Portland, USA		5.11.1964	6.1965	stricken 11.2000
Koçhisar	P116		Gölçük N Yd		12.1964	7.1965	stricken 2002

Technical data

Displacement standard, t	325
Displacement full, t	477
Length, m	52.9
Breadth, m	7.00
Draught, m	3.10 (hull)
No of shafts	2
Machinery	2 Alco 169x10AT diesels
Power, h. p.	4800
Max speed, kts	19
Fuel, t	diesel oil 60
Endurance, nm(kts)	5000(10)
Armament	1 x 1 - 40/60 Mk 3, 2 x 2 - 20/70 Mk 24, 1 x 24 - 178 Hedgehog Mk 15 ASWRL, 4 DCT, 1 DCR (21 DC)
Electronic equipment	Decca 707 radar, SQS-17A sonar
Complement	60 - 87

Standard scale images

Graphics

Project history

PC boats were built for Turkey to the wartime design.

Modernizations

late 1990s, all: - 1 x 24 - 178 Hedgehog, 4 DCT, 1 DCR, Decca 707 radar, SQS-17A sonar; + 1 x 1 - 40/60 Mk 3, Decca TM1226 radar

Naval service

No significant events.
