NAVYPEDIA


SG131 2007

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
	J21, 1981- SG21, 2002- SG121		GölçüK NSY			1968	stricken 2015-16
	J22, 1981- SG22, 2002- SG122		GölçüK NSY			1968	stricken 2015-16
	J23, 1981- SG23, 2002- SG123		Taşkizak NSY, Istanbul			1969	stricken 2015-16
	J24, 1981- SG24, 2002- SG124		Taşkizak NSY, Istanbul			1969	stricken 2015-16
	J25, 1981- SG25, 2002- SG125		Taşkizak NSY, Istanbul			1969	stricken 2015-16
	J26, 1981- SG26, 2002- SG126		Taşkizak NSY, Istanbul			1969	stricken 2015-16
	J27, 1981- SG27, 2002- SG127		Taşkizak NSY, Istanbul			1969	in service (2019)
	J28, 1981- SG28, 2002- SG128		Taşkizak NSY, Istanbul			1970	stricken 2015-16
	J29, 1981- SG29, 2002- SG129		Taşkizak NSY, Istanbul			1971	in service (2019)
	J30, 1981- SG30, 2002- SG130		Taşkizak NSY, Istanbul			1971	in service (2019)
	J31, 1981- SG31, 2002- SG131		Taşkizak NSY, Istanbul			1972	stricken 2015-16
	J32, 1981- SG32, 2002- SG132		Taşkizak NSY, Istanbul			1972	stricken 2015-16
	J33, 1981- SG33, 2002- SG133		Taşkizak NSY, Istanbul			1972	stricken 2015-16
	J34, 1981- SG34, 2002- SG134		Taşkizak NSY, Istanbul			1977	in service (2019)

Technical data

Displacement standard, t
Displacement full, t	170
Length, m	40.2
Breadth, m	6.40
Draught, m	1.65
No of shafts	2
Machinery	2 SACM-AGO 195V16 CSHR diesels / 2 cruise diesels
Power, h. p.	4800 / 300
Max speed, kts	22
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	J21-29: 2 x 1 - 40/60 Mk 3, 1 x 1 - 20/70 Mk 10 J30-34: 2 x 1 - 40/60 Mk 3, 2 x 1 - 12.7/90
Electronic equipment	Decca TM1226 radar
Complement	25

Graphics

Project history

AB25 class, sisters were built for the Navy.

Modernizations

None.

Naval service

No significant events.
