Yıldız 2008

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Yıldız	P348		Taşkizak NSY, Istanbul		3.6.1994	3.6.1996	in service (2019)
Karayel	P349		Taşkizak NSY, Istanbul		20.6.1995	19.9.1996	in service (2019)

100 - 1000 t displacement/ BRT tonnage vessels

Name No Yard No Builder Laid down Launched Comp Fate Yıldız P348   Taşkizak NSY, Istanbul   3.6.1994 3.6.1996 in service (2019) Karayel P349   Taşkizak NSY, Istanbul   20.6.1995 19.9.1996 in service (2019)

Technical data

Displacement standard, t	353
Displacement full, t	436
Length, m	54.4 pp 57.8 oa
Breadth, m	8.50
Draught, m	2.70
No of shafts	4
Machinery	4 MTU 16V538 TB91 diesels
Power, h. p.	16000
Max speed, kts	38
Fuel, t	diesel oil
Endurance, nm(kts)	3300(16)
Armament	2 x 4 Harpoon SSM (8 RGM-84C), 1 x 1 - 76/62 OTO-Melara Compact, 1 x 2 - 35/90 GDM-A, 2 x 1 - 7.6/90
Electronic equipment	Decca TM1226, AWS-6, TMX radars, LIOD Mk 2 e/o system, Cutlass, Scorpion ECM suites, 2x SRBOC Mk 36 decoy RL, TACTICOS IV CCS
Complement	45

Standard scale images

Graphics

Project history Modified German FPB 57 class.

Modified German FPB 57 class. Ordered in 1991 as an improved version of the Doğan series. Have steel hulls, aluminum superstructures, and NBC warfare defensive citadels.

Modernizations

None.

Naval service

No significant events.
