Jägaren 1997

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Jägaren	P151, 1977- P150, 2008- V150		Bergens MV, Bergen, Norway		8.6.1972	24.11.1972	stricken 2002, re-instated 2008, preserved 4.2016

Technical data

Displacement standard, t	120
Displacement full, t	150
Length, m	33.6 pp 36.6 oa
Breadth, m	6.30
Draught, m	1.70
No of shafts	2
Machinery	2 MTU 20V672 TB90 diesels
Power, h. p.	7200
Max speed, kts	35
Fuel, t	diesel oil
Endurance, nm(kts)	550(35)
Armament	6 x 1 RB-11 SSM (6 Penguin Mk 1) or (2 x 1 RB-11 SSM (2 Penguin Mk 1), 24 mines) or (2 x 1 RB-11 SSM (2 Penguin Mk 1), 2 DCR), 1 x 1 - 57/70 SAK57 Mk 1
Electronic equipment	Scanter 009, 9LV200 Mk 2 radars, SQ3D/SF sonar
Complement	22

Standard scale images

Graphics

Project history

Similar to Norwegian Snögg class.

Modernizations

1988: diesels were replaced by 2 Cummins KTA50-M (2800hp, 20kts, 550(20)nm), complement became 15; - 6 x 1 RB-11 SSM, 1 x 1 - 57/70, PEAB 9LV200 Mk 2 radar suite; + 1 x 1 - 40/70 Bofors 315, mines, nav. radar

2008: - 1 x 1 - 40/70; + 1 x 1 - 40/70 Sea Trinity, oil recovery equipment

Naval service

Jägaren was retired by navy in 2002 but reinstated by Coastal Artillery (Naval Brigade) in 2008.
