TS-2 submarine (1943 / 1944)





TS-1 and TS-2

Ships


Name No Yard No Builder Laid down Launched Comp Fate
ТС-2 [TS-2] (ex-Marsuinul)   930 Santieri Galati, Galatz, Romania 1938 22.5.1941 7.1943 // 9.1944 explosion 20.2.1945, repair incomplete


Technical data


Displacement standard, t



Displacement normal, t

636 / 860

Length, m

68.7

Breadth, m

6.45

Draught, m

3.60

No of shafts

2

Machinery

2 MAN diesels / 2 Brown-Boveri electric motors

Power, h. p.

1840 / 860

Max speed, kts

16.6 / 8

Fuel, t

diesel oil

Endurance, nm(kts)8040(10) / 86(4)
Armament

1 x 1 - 88/42 SK C/35, 1 x 1 - 20/65 C/38, 6 - 533 TT (4 bow, 2 stern, 10), 20 mines

Electronic equipmentpresumably GHG hydrophone
Complement

45

Diving depth operational, m110 (max)


Standard scale images


<i>TS-2</i> 1944
TS-2 1944


Graphics


<i>TS-1</i> and <i>TS-2</i>
TS-1 and TS-2


Project history

Former Romanian Marsuinul, 5.9.1944 captured by Soviet troops at Constanza and 14.9.1944 entered Soviet service as TS-2.

Modernizations

None.

Naval service

TS-2 20.2.1945 foundered at Poti as a result of explosion at unloading of torpedoes. 28.2.1945 she was raised and put to repair at Sevastopol. She was never commissioned again, stricken 28.11.1950 and broken up next month. Although she was renamed N-40 in August 1947 and S-40 in June 1949 and stricken only in November, 1950.
