Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
БТ-77 [BT-77], later- Комсомолец Туркмении [Komsomolets Turkmenii]		730	Sredne-Nevskiy, Pontonnyy	1964		31.12.1966	stricken 4.1990
БТ-336 [BT-336]		731	Sredne-Nevskiy, Pontonnyy			1968	stricken 4.1990
БТ-291 [BT-291]		732	Sredne-Nevskiy, Pontonnyy			1969	stricken 4.1990

Technical data

Displacement standard, t	300
Displacement full, t	320
Length, m	42.9
Breadth, m	8.25
Draught, m	2.14
No of shafts	2
Machinery	2 M-870FTK diesels
Power, h. p.	2400
Max speed, kts	13.5
Fuel, t	diesel oil
Endurance, nm(kts)	1000(10)
Armament	1 x 2 - 30/71 AK-230M, 2 DCR (22), 4 KB mines, IU-1 USV or IT-3 USV or GKT-2 mechanical, PEMT-4M magnetic or MT-3U mechanical, AT-3 acoustic or ST-2 magnetic, AT-3 acoustic or TS-1 or MPST mechanical minesweeping gear, 2 200m mine clearing line charges
Electronic equipment	Don-MN radar, MG-69 Lan', MG-79 Mezen' sonars
Complement	37

Standard scale images

Graphics

Project history

This was a further attempt to reduce signature through adoption of glass-reinforced plastic (GRP). The contract design was approved for production in 1961.

Modernizations

None.

Naval service

No significant events.
