Zabiyaka Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Забияка [Zabiyaka]		203	Cramp, Philadelphia, USA	13.7.1878	21.10.1878	11.3.1879	sunk 25.10.1904

Technical data

Displacement normal, t	1236
Displacement full, t
Length, m	67.0 pp
Breadth, m	9.10
Draught, m	4.00 max
No of shafts	1
Machinery	1 VC, 2 cylindrical boilers
Power, h. p.	1426
Max speed, kts	14.2
Fuel, t	coal 320
Endurance, nm(kts)	6000(10)
Armament	2 x 1 - 152/25 obr. 1877, 4 x 1 - 107/17 9pdr obr. 1877, 1 x 1 - 63/17 Baranovski, 4 x 1 - 44/41 Ängström, 6 x 5 - 37/17 Hotchkiss
Complement	155

Standard scale images

Graphics

Project history

Zabiyaka was laid down as merchant vessel, purchased on the stocks and completed as a clipper (sloop by international classification).

Modernizations

1890s: - 4 x 1 - 44/41; + 4 x 1 - 47/40 Hotchkiss

Naval service

Zabiyaka was sunk on shallow water 25.10.1904 in harbour of Port Arthur by shells of Japanese siege artillery. She was additionally exploded by crew by night 1-2.1.1905 before capitulation of Port Arthur, later salvaged by Japanese and broken up.
