S.K.1 motor launches (1916)







Ships


Names Builders Commissioned Losses Transfers Discarding

Zolotov Yd built: С.К.1 - 12 [S.K.1 - 12]

STPiT built (12 boats): С.К.... [S.K....]



after 5.1918 some of them were renamed as follows:

С.К.23 [S.K.23], 2.1919- №303 [No303], 9.1920- Лёгкий [Lyogkiy], 1.1921- СК-42 [SK-42], 4.1921- Лёгкий [Lyogkiy]

С.К.24 [S.K.24], 2.1919- №304 [No304], 9.1920- Ловкий [Lovkiy], 1.1921- СК-43 [SK-43], 4.1921- Ловкий [Lovkiy]

С.К.101 [S.K.101], 2.1919- №305 [No305], 9.1920- Летучий [Letuchiy], 1.1921- СК-44 [SK-44], 4.1921- Летучий [Letuchiy]

С.К.102 [S.K.102]

С.К.103 [S.K.103], 2.1919- №306 [No306], 9.1920- Лихой [Likhoy], 1.1921- СК-45 [SK-45], 4.1921- Лихой [Likhoy]

С.К.104 [S.K.104]

Zolotov Yd, Petrograd: 12 boats

Severnoye Tovarishchestvo Parokhodstva i Torgovli, Petrograd: 12 boats

1916 - 1917: 24 boats

S.K.10 (1.12.1916)

none

1918: S.K.102

1927: SK-45

1929: SK-44

1930: SK-42, 43

fate of 6 boats is unknown



Technical data


Displacement normal, t

16

Displacement full, t16
Length, m

16.8

Breadth, m

2.84

Draught, m

1.07

No of shafts

2

Machinery

2 petrol engines

Power, h. p.

Zolotov built boats: 250

STPiT built boats: 300

Max speed, kts

Zolotov built boats: 20

STPiT built boats: 21

Fuel, t

petrol

Endurance, nm(kts)
Armament

1 x 1 - 47/40 Hotchkiss, 1 x 1 - 7.6/94

Complement

15



Standard scale images


<i>S.K.1</i> (Zolotov-built) 1917
S.K.1 (Zolotov-built) 1917
STPiT-built ML
STPiT-built ML


Graphics






Project history

Patrol motor launches built for service on Baltic.

Modernizations

None.

Naval service

No significant events.
