Pervenets

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Первенец [Pervenets]			Tyne Iron SB, London, UK	12/1861	18.5.1863	28.7.1863	stricken 10.1905
Не Тронь Меня [Ne Tron' Menya]			Galerny Is, St. Petersburg	27.1.1863	23.6.1864	18.7.1865	stricken 10.1905
Кремль [Kreml']			Semyannikov & Poletika Wks, St. Petersburg	2.10.1863	26.8.1865	1867	stricken 10.1905

Technical data

Displacement normal, t	Pervenets: 3622 Ne Tron' Menya: 3494 Kreml': 3412
Displacement full, t	Kreml': 4000
Length, m	Pervenets: 67.6 Ne Tron' Menya: 69.4 Kreml': 67.3
Breadth, m	16.2
Draught, m	Pervenets: 4.50 Ne Tron' Menya: 4.57 Kreml': 4.60
No of shafts	1
Machinery	Pervenets: 1 HDA, 2 rectangular boilers Ne Tron' Menya, Kreml': 1 HDA, 4 rectangular boilers
Power, h. p.	Pervenets: 1067 Ne Tron' Menya: 1232 Kreml': 870
Max speed, kts	Pervenets, Ne Tron' Menya: 8 Kreml': 9
Fuel, t	coal 500
Endurance, nm(kts)
Armour, mm	Pervenets: wrought iron; belt: 114, battery: 114 Ne Tron' Menya: wrought iron; belt: 114, battery: 114, CT: 114 Kreml': wrought iron; belt: 114, battery: 140, deck: 29, CT: 114
Armament	Pervenets: 26 x 1 - 196/12 SBML Ne Tron' Menya, Kreml': 17 x 1 - 196/12 SBML
Complement	Pervenets: 459 Ne Tron' Menya: 394 Kreml': 430

Standard scale images

Graphics

Project history

Broadside iron-hulled coast defence ships with projecting bows and pronounced tumblehome, particularly in Pervenets. The engines of the two latter ships came from Russian wooden screw ships, and all three were rigged as three-masted schooners.

Ship protection

The hull was completely armoured above water except in Kreml' where the battery armour was not taken to the bow and stern.

Modernizations

1867, Pervenets: was armed with 3 x 1 - 203/19 obr. 1867, 21 x 1 - 196/12 SBML

1867: Ne Tron' Menya: was armed with 17 x 1 - 203/19 obr. 1867

1867, Kreml': - 3 x 1 - 196/12; + 2 x 1 - 203/19 obr. 1867

1868, Kreml': - 2 x 1 - 203/19; + 2 x 1 - 196/12 SBML, 2 x 1 - 152/23 obr. 1867, 4 x 1 - 87/17 4pdr obr. 1867

1870, Kreml': - 5 x 1 - 196/12, 4 x 1 - 87/17; + 6 x 1 - 203/19 obr. 1867

1874, Pervenets: - 21 x 1 - 196/12; + 9 x 1 - 203/19 obr. 1867, 2 x 1 - 87/17 4pdr obr. 1867

1874, Kreml': - 9 x 1 - 196/12, 2 x 1 - 152/23; + 10 x 1 - 203/19 obr. 1867, 6 x 1 - 87/17 4pdr obr. 1867

1876, Ne Tron' Menya: - 1 x 1 - 203/19; + 4 x 1 - 87/17 4pdr obr. 1867

1877, Pervenets: - 2 x 1 - 203/19; + 2 x 1 - 152/23 obr. 1867, 1 x 1 - 107/17 9pdr obr. 1867, 2 x 1 - 87/17 4pdr obr. 1867

1877, Kreml': - 2 x 1 - 203/19, 2 x 1 - 196/12; + 1 x 1 - 229/19 obr. 1877, 1 x 1 - 44/41 Ängström

1880, Pervenets: - 2 x 1 - 152/23, 2 x 1 - 87/17; + 1 x 1 - 229/19 obr. 1877, 4 x 1 - 152/25 obr. 1877, 2 x 1 - 47/40 Hotchkiss, 1 x 1 - 44/41 Ängström, 1 x 5 - 37/17 Hotchkiss

1880, Kreml': - 1 x 1 - 229/19, 2 x 1 - 203/19, 6 x 1 - 87/17, 1 x 1 - 44/41

1881, Ne Tron' Menya: - 2 x 1 - 203/19; + 1 x 1 - 44/41 Ängström

1890s, Pervenets: - 1 x 1 - 229/19, 4 x 1 - 203/19, 1 x 1 - 44/41; + 2 x 1 - 152/32 obr. 1877, 2 x 1 - 120/43 Canet, 2 x 1 - 63/17 Baranovski, 4 x 5 - 37/17 Hotchkiss

1890s, Ne Tron' Menya: - 2 x 1 - 203/19, 4 x 1 - 87/17, 1 x 1 - 44/41; + 2 x 1 - 152/25 obr. 1877, 2 x 1 - 63/17 Baranovski

1890s, Kreml': - 4 x 1 - 203/19; + 7 x 1 - 152/32 obr. 1877, 2 x 1 - 63/17 Baranovski, 4 x 1 - 47/40 Hotchkiss, 4 x 1 - 37/20 Hotchkiss

Naval service

No significant events.
