Ships

Name	Yard No	Builder	Laid down	Launched	Comm	Fate
Хасан [Khasan] (ex-Лазо [Lazo])	233/9671	112 Yd, Gorkiy // Kirov Wks, Khabarovsk	15.7.1936 // 4.11.1939	30.8.1940	1.2.1942	stricken 3.1960
Перекоп [Perekop] (ex-Симбирцев [Simbirtsev])	234/9672	112 Yd, Gorkiy // Kirov Wks, Khabarovsk	15.7.1936 // 19.12.1939	14.6.1941	24.12.1943	stricken 3.1960
Сиваш [Sivash] (ex-Серышев [Seryshev])	235/9673	112 Yd, Gorkiy // Kirov Wks, Khabarovsk	15.7.1936 // 20.8.1940	1.10.1941	31.10.1946	accommodation  ship 9.1960

Technical data

Displacement standard, t	1704
Displacement full, t	2400
Length, m	88.0
Breadth, m	11.1
Draught, m	2.94 full load
No of shafts	4
Machinery	4 38KR-8 diesels
Power, h. p.	3200
Max speed, kts	15
Fuel, t	diesel oil 167
Endurance, nm(kts)	5510(11)
Armour, mm	belt: 77 - 36, turrets: 100 - 50, CT: 100 - 50, deck: 40 - 25, bulkheads: 25
Armament	Khasan: 3 x 2 - 130/50 B-28, 2 x 2 - 76/52 39K, 2 x 2 - 45/43 41K, 5 x 2 - 12.7/79, 29 mines Perekop: 3 x 2 - 130/50 B-2-LMT, 2 x 2 - 76/52 39K, 2 x 2 - 45/43 41K, 5 x 2 - 12.7/79, 29 mines Sivash: 3 x 2 - 130/51 B-2-LMT, 2 x 2 - 76/55 39K, 2 x 2 - 45/46 41K, 5 x 2 - 12.7/79, 29 mines
Complement	242

Standard scale images

Graphics

Project history

The largest and strongest river combat ships in the world. Seaworthy monitors for operations in lower Amur and in the Tartar Strait. The design was developed since 1935 with usage of the project of the large monitor of 1915. Originally the armament should include 4 twin 130mm turrets, arranged superfiring, and also a seaplane, but because of the overload which have arisen in the course of building the aircraft was refused, the aft superfiring 130mm turret was replaced by 2 twin 76mm mounts. The flat-bottom hull had ice stiffenings and a forecastle, allowing to go out in the high sea.      Three monitors were laid down at Gorky in 1936; by summer of 1939 sections were transported to Khabarovsk for completion. Completion became complicated a delay of availability of turrets, because of what Perekop was completed with 3 single 130mm guns.

Ship protection

  Main belt had 77mm thickness amidships and 36mm at ship ends, citadel was closed by 25mm bulkheads. Deck was 40mm amidships and 25mm at ship ends. CT and turrets had 100-50mm protection, MG turrets had 10mm armour.

Modernizations

None.

1/1946, Khasan: 3 x 2 - 130/51 B-28, 2 x 2 - 76/55 39K, 2 x 2 - 45/46 41K, 5 x 2 - 12.7/79, 29 mines

1/1946, Perekop: 3 x 2 - 130/51 B-2-LMT, 2 x 2 - 76/55 39K, 2 x 2 - 45/46 41K, 5 x 2 - 12.7/79, 29 mines

Naval service

During war Khasan and Perekop were a part of North Pacific Flotilla.
