Piorun 2008 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Orkan	421	390 // 660/1	Peenewerft, Wolgast, East Germany // Stocznia Polnocna, Gdansk	13.9.1989	7.7.1990	18.9.1992	in service (2019)
Piorun	422	391 // 660/2	Peenewerft, Wolgast, East Germany // Stocznia Polnocna, Gdansk	10.7.1990	19.10.1990	13.3.1994	in service (2019)
Grom (ex-Huragan)	423	392 // 660/3	Peenewerft, Wolgast, East Germany // Stocznia Polnocna, Gdansk	18.9.1989	11.12.1990	28.4.1995	in service (2019)

Technical data

Displacement standard, t	331
Displacement full, t	396
Length, m	45.0 pp 48.9 oa
Breadth, m	8.65
Draught, m	2.15
No of shafts	3
Machinery	3 M-520 diesels
Power, h. p.	16200
Max speed, kts	36
Fuel, t	diesel oil
Endurance, nm(kts)	1600(18)
Armament	1 x 4 FAM-14 SAM (8 9M32M Strela-2M), 1 x 1 - 76/59 AK-176, 1 x 6 - 30/54 AK-630M
Electronic equipment	NUR-27XA, SRN-443, MR-123 Vympel-AME radars, PK-32 Jastrzab, 8x PK-12 Derkacz-2 decoy RL
Complement	36

Standard scale images

Graphics

Project history

Former East German project 151A craft, purchased incomplete without engines and armament prior the unification of Germany. Completed for Polish navy as project 660 instead of cancelled indigenous project 665.

Modernizations

2003, Piorun; 2005, Grom; 2007, Orkan: - NUR-27XA, SRN-443, MR-123 Vympel-AME radars, + 4 x 2 RBS-15 Mk 2 SSM (8 RBS-15 Mk 2), Sea Giraffe AMB 3D, CRM-200, Sting-EO radars, Bren ECM suite, TACTICOS CCS

2011-2012, all: - 4 x 2 RBS-15 Mk 2 SSM; + 4 x 2 RBS-15 Mk 3 SSM (8 RBS-15 Mk 3)

Naval service

No significant events.
