Holland 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
Holland	P840		Damen Schelde, Vlissingen + Damen, Galati, Romania	8.12.2008	2.2.2010	6.7.2012	in service (2019)
Zeeland	P841		Damen Schelde, Vlissingen + Damen, Galati, Romania	22.9.2009	20.11.2010	23.8.2013	in service (2019)
Friesland	P842		Damen, Galati, Romania + Damen Schelde, Vlissingen	26.11.2009	4.11.2010	22.1.2013	in service (2019)
Groningen	P843		Damen, Galati, Romania + Damen Schelde, Vlissingen	9.4.2010	21.4.2011	29.11.2013	in service (2019)

Technical data

Displacement standard, t	3000
Displacement full, t	3750
Length, m	102.4 pp 108.4 oa
Breadth, m	16.0
Draught, m	4.55
No of shafts	2
Machinery	2 MAN 12V 28/33D diesel-generators, 2 electric motors
Power, h. p.	14700
Max speed, kts	22
Fuel, t	diesel oil
Endurance, nm(kts)	5000(16)
Armament	1 x 1 - 76/62 OTO-Melara Compact, 1 x 1 - 30/82 Marlin, 2 x 1 - 12.7/90, 6 x 1 - 7.6/90, 1 helicopter (NH 90)
Electronic equipment	SMILE, Seastar, 2x Selesmar radars, Gatekeeper e/o system, SEWACO CCS
Complement	55 + 40 passengers

Standard scale images

Graphics

Project history

Ordered in 2007. The ships are built in sections with work being shared between Damen Schelde's shipyards in Vlissingen, Netherlands, and Galati, Romania. The ships are quite large by patrol standards and are heavier than the Karel Doorman-class frigates. The class is intended for low-threat environments and missions including maritime interdiction, humanitarian relief, and general patrol duties. Two 12m RIBs are carried; one can be launched and recovered via a stern ramp, and the second with portside davits. Primary sensors are housed in a single integrated mast module. A 10t cargo crane is fitted on the starboard side aft of the hangar, and additional room is provided to accommodate two 20ft equivalent (TEU) container modules in a compartment beneath the flight deck.

Modernizations

None.

Naval service

No significant events.
