NAVYPEDIA


Mano 1976

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
103 Cavilla 104 Mano	Swiftships, Morgan City, USA: 103, 104	1976: 103, 104	103 (early 1990s), 104 (early 1990s)	none	none

Technical data

Displacement standard, t
Displacement full, t	38
Length, m	19.8
Breadth, m	5.80
Draught, m	0.80
No of shafts	2
Machinery	2 General Motors 12V71TI diesels
Power, h. p.	1920
Max speed, kts	24
Fuel, t	diesel oil
Endurance, nm(kts)	600(21.5)
Armament	2 x 1 - 12.7/90, 1 x (1 - 12.7/90 + 1 - 81/12 mortar)
Electronic equipment	radar
Complement	20

Graphics

Project history

US 65ft Sewart Commercial Cruiser design. Aluminium hull.

Modernizations

None.

Naval service

Both boats were transferred under the naval flag in 1987 (Coast Guard was renamed the Liberian Navy). They were lost during the civil war, fate of the boats is unknown.

© Ivan Gogin, 2019
