Tanikaze

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
江風 [Kawakaze]			Yokosuka K K	2.1917	10.10.1917	11.1918	stricken 4.1934
谷風 [Tanikaze]			Maizuru K K	9.1916	20.7.1918	1.1919	hulk 4.1935

Technical data

Displacement normal, t	1300
Displacement full, t	1580
Length, m	97.6 pp 103.6 oa
Breadth, m	8.80
Draught, m	2.80
No of shafts	2
Machinery	Kawakaze: 2 sets Parsons geared steam turbines, 4 Kampon boilers Tanikaze: 2 Curtis steam turbines, 4 Kampon boilers
Power, h. p.	34000
Max speed, kts	37.5
Fuel, t	oil 380
Endurance, nm(kts)	4000(15)
Armament	3 x 1 - 120/45 3-shiki, 2 x 1 - 7.7/87, 3 x 2 - 533 TT
Complement	128

Standard scale images

Graphics

Project history

The improved variant of Isokaze, differed from a prototype by more powerful machinery with oil-firing boilers and, accordingly, increased speed. Number of 120mm guns was lowered, but calibre of torpedoes has increased to 533mm.

Modernizations

1920s, both: - 3 x 2 - 533 TT; + 2 x 3 - 533 TT.

Naval service

As hulks both ships have lived to the Second World War.
