Mizuho

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
瑞穂 [Mizuho]			Kawasaki, Kobe	16.5.1937	16.5.1938	25.2.1939	sunk 2.5.1942

Technical data

Displacement standard, t	10929
Displacement full, t	12150
Length, m	174.0 pp 183.6 wl 192.5 oa
Breadth, m	18.8
Draught, m	7.08
No of shafts	2
Machinery	2 diesels
Power, h. p.	15200
Max speed, kts	22
Fuel, t	diesel oil 1000
Endurance, nm(kts)	8000(16)
Armament	3 x 2 - 127/40 89-shiki, 6 x 2 - 25/60 96-shiki, 24 seaplanes (E4N, E7K, E8N, E10A, E11A) or (12 seaplanes (E4N, E7K, E8N, E10A, E11A), 12 А-gata midget submarines)
Complement

Graphics

Aircraft facilities

There were 4 catapults. Seaplanes based on deck and in hangar. There were 2 lifts. 8 additional seaplanes carried as reserve. Aircraft fuel stowage was 900 t.

Project history

Design was created on the basis of drawings of seaplane tenders of Chitose class, ship was built under 3rd Supplementary Programme of 1937. Main differences concerned machinery structure: instead of combined diesel-turbine, installed on a prototype, Mizuho have been equipped by only diesels. Though it has called appreciable decrease in a speed, it was possible to increase hangar size, having prolonged it fwd. The number of carried spare seaplanes has increased to 8. A hinged platform as that on Mizuho was not, and pairs of pylons were connected among themselves by bridges.

Modernizations

early 1942: + 3 x 2 - 25/60 96-shiki

Naval service2.5.1942 Mizuho was sunk at cape Omisaka (Honshu) by American submarine Drum.

2.5.1942 Mizuho was sunk at cape Omisaka (Honshu) by American submarine Drum.
